Linked with Auto Run

Timed (No = Cont)

Reversible

Has Zero Spd Sw

Linked with Auto Run
This is a switch (Y/N) that links the running of the cleanout conveyor with the
running of the belt. If this is set for "Y", the drag chain will only run if the belt
is running, and will not run if the belt is not running. Note: If the drag chain is
set for "Timed" operation (see below), the drag chain will cycle while the belt
is running, even though the belt is running continuously.
If this option is set for "N", the drag chain will only run when started from the
User Interface (see Main Menu > Drag Chain Control), and will only stop
when stopped from the User Interface.

Timed

This is a switch (Y/N) that indicates if the cleanout conveyor should cycle on
and off, or run continuously. A setting of "Y" indicates timed operation, and a
setting of "N" indicates continuous. See "Numeric Data" below for the timer
settings.
Reversible
This is a switch (Y/N) that indicates if the cleanout conveyor can run
backwards. If this is enabled, then it will be possible to run the drag chain in
reverse from the User Interface.
Has Zero Spd Sw
If a proximity (or other type) switch has been installed to monitor the motion
of the drag chain, this feature can be turned on to provide a Zero Speed
function. Enabling this feature adds an additional Logical Input called "Drag
Chain ZSS" and an additional Logical Output called "Drag Chain Jam".
Numeric Data
The following numeric parameters can be set for the Drag Chain:
