Tachos

(Main Menu > Advanced Setup > Tachos)
Selecting this menu item, you will be presented with the following menu:
Function...
Tacho 1
Tacho 2
Numeric Data...
Note: Not all menu items will appear, depending on how many Tachos are configured
(see Main Menu > Advanced Setup > Configuration).
Function
This setting describes the functionality of the tacho or tachos, if more than one is
configured. The available options are:
First Only
Second Only
First (Pri) Second (Slip)
Second (Pri) First (Slip)
First (Pri) Second (ZSpd)
Second (Pri) First (ZSpd)
Analog Input
From Network
Simulator
None
First Only
This is the setting to use if you have only one tacho connected and it is
connected to the Tacho 1 port on the GCM. This is the tacho that will be used
for all functions within the controller. Note: This tacho may be a 2-channel (i.e.
quadrature), but it is still considered one tacho.
Note: The Configuration settings should bet set to enable only Tacho 1 (see
Main Menu > Advanced Setup > Configuration > Tacho 1).
Page 46 of 104
↑
↓
↑
↓
