Page 1: Quick Start Guide
Illustra Pro 12MP Fisheye Quick Start Guide 8200-1485-01 C0... -
Page 2: Customer Service
Customer Service Thank you for using Illustra products. We support our products through an extensive worldwide network of dealers. The dealer through whom you originally purchased this product is your point of contact if you need service or support. Our dealers are empowered to provide the very best in customer service and support. - Page 3 Safety Notice The recessed indoor camera models are rated as suitable for use in environmental air handling spaces, except inside air ducts or furnace plenums. CAUTION: Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. ESD Precautions: With the covers removed during installation and allignment this product is sensitive to electrostatic discharge.
-
Page 4: Table Of Contents
Illustra Connect Key functions of Illustra Connect Discovering the Illustra Camera lllustra Connect Configuring the Illustra Camera using a Static IP Address Physical Reset of the Camera Resetting the Camera to Factory Default Settings Using the Reset Button Technical Specifications... - Page 5 Firewall Illustra API Version Discovery UPnP Discovery ONVIF Video and Control Interface Interface Technical Specifications ONVIF Functions Supported microSD Card Environmental Power Regulatory Compliance Appendix A: Camera Defaults for Fisheye Camera...
-
Page 6: Product Features
Product Features Features • Mega pixel HD up to 12MP Resolution • Supports three independently configurable streams • Edge Dewarping, • Three Stream Compression: Baseline / Main /H264 high only supported/ MJPEG • Multiple Dewarping modes: Active Image (ePTZ) / Panorama View / Quad View / Combi •... -
Page 7: Dimensions
Dimensions Figure 1 Fisheye Camera dimensions Illustra Pro 12MP Fisheye Quick Start Guide... -
Page 8: What's In The Box
Please caheck the box contains the items listed here. If any item is missing or has defects do not install or operate the product and contact the dealer for assistance. Illustra Pro 12MP Fisheye Camera Security Torx Power Terminal Block... -
Page 9: Mounting The Camera
Figure 3 Mounting Installation Template Note: • You can also print and use the template provided on the disk in the box when mounting the camera. • Size of actual template on disc is 150mm x 150mm. Illustra Pro 12MP Fisheye Quick Start Guide... - Page 10 4s electrical box (inside) Pendant mounts Note: To mount the camera onto pendant mounts, one of the following will be required: • Illustra Pendant Cap outdoor white, 3/4 "NPT (ADC16DPCAPOW) • Illustra Pendant Cap outdoor black kit,3/4" NPT (ADCI6DPCAPOB) Figure 5 Adaptor Plate...
-
Page 11: Cable Sealing
Apply the self-fusing tape where each cable enters the tubes making sure it overlaps itself, the tube, and the cable. Illustra Pro 12MP Fisheye Quick Start Guide... -
Page 12: Connecting The Camera
Connecting the Camera Loosen the security screws by twisting the security torx and open the cover to reach the connectors. Figure 6 Location of security screws Figure 7 Camera connectors Connector Definition 1=Power Power Connection 2=GND RJ-45 For network and PoE connections microSD Card Slot Insert the microSD card into card slot to store videos and snapshots. -
Page 13: Powering The Camera
Orange Activity Light flashes for network activity indication. Note: • If the LEDs are unlit, please check the LAN connection. • In some cases, Ethernet crossover cable might be needed when connecting the camera directly to the Illustra Pro 12MP Fisheye Quick Start Guide... -
Page 14: Desiccant Bag Installation
Desiccant Bag Installation You can install the desiccant bag (IP12FEDESIBAG: Pro 12MP Fisheye Desiccant Bag) into the camera by performing the following procedure. Installing the desiccant bag Step Action Unscrew both top cover screws and remove the top cover. Figure 9 : Camera top cover and screws Remove the desiccant bag from the sealed bag and remove the protective membrane from the double- sided tape. - Page 15 Figure 12 : Desiccant bag placement location (left side) Desiccant bag in the camera (right side) Place the top cover on the camera and secure both screws. Note:To help provide maximum protection against condensation you should replace the desiccant bag each time you remove the top cover. Illustra Pro 12MP Fisheye Quick Start Guide...
- Page 16 Figure 13 : Top cover securely fitted - End -...
-
Page 17: Accessing The Camera For The First Time
IP addresses, or naming cameras without seeing where they are pointed, often results in longer installations. Illustra Connect eliminates all of these issues with a unique feature set that includes a one-touch IP conflict resolver and snapshot tool . Simply bring up all of the cameras out of the box, enter the IP range provided by the customer's IT department and click OK. -
Page 18: Discovering The Illustra Camera
The following information states how to install and access the camera. lllustra Connect The following information states how to install and access the camera on your network using the Illustra Connect discovery tool. Illustra Connect enables automatic discovery of compliant devices on IP networks and is the recommended method for installation and detection of the camera on the network. -
Page 19: Configuring The Illustra Camera Using A Static Ip Address
• We recommend that once you are logged into the Web Configuration pages you change the Static IP Address of the camera so that conflicts can be avoided when using the same Static IP Address to setup additional cameras. • In a situation where IP address conflicts arise, Illustra Connect can be used to discover the device. -
Page 20: Physical Reset Of The Camera
Physical Reset of the Camera It is possible to perform a physical reset to factory defaults using the reset button located on the underside of the camera. Resetting the Camera to Factory Default Settings Using the Reset Button The reset button can be used to restore the camera to the factory default settings. Note: It is not possible to retain network settings, presets, patterns or sequences when using this procedure. -
Page 21: Technical Specifications
Technical Specifications This section provides information on the technical, environmental and operating specifications for the Illustra Pro Fisheye Camera. Illustra Fisheye Product Description Product Code IPS12FFOCWIY/ Illustra Pro 12 MP Fisheye, indoor/outdoor, white TDN w/IR, WDR IPS12FFOCWIYx Technical Specifications Specification... -
Page 22: Resolution
• The following mount image source combinations are possible: Ceiling mount view modes: Fisheye Ceiling panorama Quad Active Image (4x ePTZ) Active Image Wall mount view modes: Fisheye Wall panorama Combi (panorama + 2 ePTZ) Active Image Illustra Pro 12MP Fisheye Quick Start Guide... - Page 23 • Dewarping will apply to only GUI stream and does not affect RTSP or Server connected stream Edge Dewarp 2nd Stream Stream Stream Image Symbol Max fps H.264 or MJPEG H.264 or MJPEG H.264 or MJPEG Source (2688x1512) 16:9 (1920x1080) 1080p 16:9 (960x544) 16:9 (960x544) 16:9 Ceiling...
-
Page 24: Base Protocol And Underlying Layers
•Dynamic DNS or DDNS Dynamic Domain Name System is supported for updating, in real time a changing IP address on the Internet to provide a persistent domain name for a resource that may change location on the Illustra Pro 12MP Fisheye Quick Start Guide... -
Page 25: Network Name Resolution
network. RFC 2136 Dynamic Updates in the Domain Name System. In this situation the camera talks only to the DHCP server and the DHCP server is responsible for updating the DNS server. The camera sends its hostname to the DHCP server when requesting a new lease and the DHCP server updates the DNS records accordingly. This is suitable for an intranet style configuration where there is an internal DHCP and DNS service and the user wants only to access their camera within their own network. -
Page 26: Illustra Api Version
Discovery The product supports WS-Discovery and UPnP discovery. A copy of illustra Connect is supplied with the camera, this is a MS-Windows based discovery application, which will allow discovering any illustra camera on a network. For each camera found on the network, the discovery tools will report: •... -
Page 27: Onvif Video And Control Interface
Details Description Language WSDL Web Services Specification DPWS Web Services Tool Kit WS4D Web Services Protocol SOAP Message Format WS Discovery, ONVIF discovery, Illustra Connect discovery, uPnP Discovery discovery Security WS-Security Video Transport RTP/RTSP Audio Transport RTP/RTSP • WS-Eventing • WS-Base Notification Event Handling (alarms) •... -
Page 28: Onvif Functions Supported
Usable with PoE and DC12 sources with up to 100m (300 feet) of cable; with compliance verification including power over Ethernet compliant to POE IEEE 802.3afTM and power over Ethernet Plus compliant to POE IEEE 802.3atTM. Power consumption is capped at 12.95Watts. Illustra Pro 12MP Fisheye Quick Start Guide... -
Page 29: Regulatory Compliance
Regulatory Compliance The Illustra Pro Fisheye Camera meets the following regulatory requirements: USA (FCC): CFR 47 Part 15 Canada: ICES-003/NMB-003 Issue 5 European Union: EN 55022:2010 European Union: EN 61000-3-2:2006/A2:2009 European Union: EN 61000-3-3:2008 Australia/New Zealand: AS/NZS CISPR 22:2009 EN50130-4:2011... -
Page 30: Appendix A: Camera Defaults For Fisheye Camera
Input Volume 10dB Output Enable Audio out Output Volume Privacy Zone Privacy Zone Disabled Network Settings IP & Ethernet Camera name Same as camera friendly name Authority: administrator User management Default account Username/Password: admin/admin Illustra Pro 12MP Fisheye Quick Start Guide... - Page 31 Network Settings Language Basic Settings English DHCP Enabled IP v4 Always on IPv6 Enabled IP v6 address Camera specific IP Settings IP v4 address 192.168.1.168 IP v4 Subnet Mask 255.255.255.0 Default Gateway 192.168.1.254 0.0.0.0 HTTP Port Enabled FTP Server IP Address 0.0.0.0 FTP Server Port Username...
- Page 32 White Balance Blue Brightness Sharpness Picture Adjustment Contrast 50 % Saturation Disabled IR Mode Enabled IR/DayNight Day Night Mode Auto Mid Dewarp Method Client Dewarp Mount Ceiling PTZ Settings Left Scan Limits Right Illustra Pro 12MP Fisheye Quick Start Guide...
