- Page 1 Illustra Essentials Indoor / Outdoor HD Bullet User Manual 8200-1102-02 B0...
-
Page 2: Customer Service
Notice Please read this manual thoroughly and save it for future use before attempting to connect or operate this unit. The information in this manual was current when published. The manufacturer reserves the right to revise and improve its products. All specifications are therefore subject to change without notice. Copyright Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form, in whole or in part, without prior written consent of... -
Page 3: Important Safeguards And Warnings
Important Safeguards and Warnings 1．Electrical safety All installation and operation should conform to your local electrical safety codes. The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please note: Do not connect two power supplying sources to the device at the same time;... - Page 4 Please shut down the device and then unplug the power cable before you begin daily maintenance work. Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens surface. Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean the device.
-
Page 5: Table Of Contents
Table of Contents Important Safeguards and Warnings ........................ii Table of Contents .............................. iv General Introduction ............................1 Overview ..............................1 Features ..............................1 Specifications ..............................2 Performance .............................. 2 Framework ................................. 5 Cable ................................. 5 Framework and Dimension ........................6 Device Installation .............................. -
Page 6: General Introduction
General Introduction Overview This series network camera integrates the traditional camera and network video technology. It adopts video data collection, transmission together. It can connect to the network directly without any auxiliary device. This series network camera uses standard H.264 video compression technology, which maximally guarantees the video quality. -
Page 7: Specifications
Specifications Performance Please refer to the following sheet for network camera performance specification. Model IE01MFBNWIY Parameter Main Processor High performance DSP Embedded LINUX System Support real-time network, local record, and remote operation at the same Resources time. User Interface Remote operation interface such as WEB, DSS, PSS System Status Bit stream statistics, log, and software version. - Page 8 Temperature ≤95% Working Humidify Dimensions(mm) 70*66*155 Weight 620g Installation Installation with the bracket. Model IE02MFBNWIY Parameter Main Processor High performance DSP Embedded LINUX System Support real-time network, local record, and remote operation at the same Resources time. User Interface Remote operation interface such as WEB, DSS, PSS System Status Bit stream statistics, log, and software version.
- Page 9 Snapshot Max 1f/s snapshot. File extension name is JPEG. Privacy Mask Supports max 4 privacy mask zones Video Setup Support parameter setup such as bright, contrast. Video Information Channel title, time title, motion detect, tampering. Lens 3.6mm, 6mm, 8mm. Fixed focus. Lens Interface M12.
-
Page 10: Framework
Framework Cable You can refer to the following figure for cable information. See Figure 2-1 Figure 2-1 Cable Please refer to the following sheet for detailed information. Port Function Connection Note Name Connect to standard Ethernet cable. Ethernet Note: Some devices do not support PoE. Network port port Before making crystal head, pull the anti-dust, waterproof cover... -
Page 11: Framework And Dimension
Framework and Dimension Please refer to the following figure for dimension information. The unit is mm. See Figure 2-2 to Figure 2-4. Figure 2-2 Figure 2-3... - Page 12 Figure 2-4...
-
Page 13: Device Installation
Device Installation Note Before the installation, please make sure the installation environments can at least support 3x weight of the camera. Figure 3-1 Device installation 1 Please see Figure 3-1 and Figure 3-2. Step 1 Stick installation sticker to designated surface where you will install the device (wall or ceiling). Step 2 Dig a hole according to position of hole on installation sticker. - Page 14 Figure 3-2 Device installation 2 Step 6 Use Philip’s head screw (in accessories bag) to loosen adjusting screw. Step 7 Adjust the device in all possible directions, and set its monitoring direction. Step 8 Use Philip’s head screw to tighten the screws.
-
Page 15: Quick Configuration Tool
Quick Configuration Tool Overview Quick configuration tool can search current IP address, modify IP address. At the same time, you can use it to upgrade the device. Please note the tool only applies to the IP addresses in the same segment. Operation Double click the “ConfigTools.exe”... - Page 16 If you want to modify the device IP address without logging in the device web interface, you can go to the configuration tool main interface to set. In the configuration tool search interface (Figure 4-1), please select a device IP address and then double click it to open the login interface.
-
Page 17: Web Operation
Web Operation This series network camera products support the Web access and management via PC. Web includes several modules: Monitor channel preview, system configuration, alarm and etc. Network Connection Please follow the steps listed below for network connection. • Make sure the network camera has connected to the network properly. •... - Page 18 Figure 5- 2 Web login After you successfully logged in, please install WEB plug-in unit. Please refer to the Web Operation Manual included in the resource CD for detailed operation instruction. See Figure 5- 3. Figure 5- 3 Web monitoring window...
-
Page 19: Faq
I can not boot up Please click RESET button for at least five seconds to restore factory the device or default setup. operate properly. The water leakage The unauthorized front or rear cap remove many result in water occurred. leakage. -
Page 20: Appendix Toxic Or Hazardous Materials Or Elements
Appendix Toxic or Hazardous Materials or Elements Toxic or Hazardous Materials or Elements Component Name Cr VI PBDE Circuit Board ○ ○ ○ ○ ○ ○ Component ○ ○ ○ ○ ○ ○ Device Case ○ ○ ○ ○ ○ ○...
