Sentinel Pro Installation and Setup Guide
Wall Mount InstallatIon
The Sentinel Pro can be wall mounted using dry wall anchors and (4) #8 screws. Follow the steps
below:
1) Install four drywall anchors (if necessary). Attach the Sentinel Pro using four #8 tapping screws. See
Figure 2 for dimensions.
2) Attach sensors to the zone terminals.
3) Plug the power adaptor into a 115VAC 50/60Hz outlet.
4) Connect a CAT5 cable to the Ethernet port and connect to a 10/100 network hub, switch or router.
sentInel Cellular VersIon
The Cellular version of the Sentinel Pro includes a 4G modem and battery backup system to keep the
entire unit functioning for up to 8 hours. A special Battery Backup Controller is included to maintain
proper charging of the 12V backup battery and automatically switchover when power fails. The unit is
packaged in a NEMA-4X Polycarbonate enclosure with a universal 12V power supply. Cellular subscrip-
tion plans are available from Sensaphone.
Mounting Dimensions (Cellular):
12
3.00
5.75"
Figure 2: Sentinel Pro mounting dimensions
10.54"
268mm
13.3"
334mm
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the Sentinel Pro and is the answer not in the manual?
Questions and answers
How do you add users?
To add users to Sensaphone Sentinel Pro:
1. Go to the "Manage Users" page.
2. Add alarm users to your account.
3. To group users, go to the "Manage user groups" section.
4. Select an existing group or click "Create New Group."
5. Give the group a unique, descriptive name.
6. Click the plus icon to add users from the list of alarm users.
7. You can add an entire user or select individual destinations.
8. Click the red X icon to remove users if needed.
9. Click "Save Group" when finished.
This answer is automatically generated
