- Page 1 SENSAPHONE ® IMS–4000 ™ IMS-4010 Dry Contact Node User’s Manual SENSAPHONE ® LIT-0172...
- Page 2 Every effort has been made to ensure that the information in this document is complete, accurate and up-to-date. Sensaphone assumes no responsibility for the results of errors beyond its control. Sensaphone also cannot guarantee that changes in equipment made by other manufacturers, and referred to in this manual, will not affect the applicability of the information in this manual.
-
Page 3: Important Safety Instructions
• Read and follow all warning and instruction labels on the product itself. • To protect the IMS-4010 from overheating, make sure all openings on the unit are not blocked. Do not place on or near a heat source, such as a radiator or heat register. - Page 4 THIS LIMITED WARRANTY CONTAINS SENSAPHONE’S STANDARD TERMS AND CONDITIONS. WHERE PERMITTED BY THE APPLICABLE LAW, BY KEEPING YOUR SENSAPHONE PRODUCT BEYOND THIRTY (30) DAYS AFTER THE DATE OF DELIVERY, YOU FULLY ACCEPT THE TERMS AND CONDITIONS SET FORTH IN THIS LIMITED WARRANTY.
- Page 5 State of Delaware, without regard to the principles of conflicts of law. Effective date 04/01/2009 PHONETICS, INC. d.b.a. SENSAPHONE 901 Tryens Road Aston, PA 19014 Phone: 610.558.2700 Fax: 610.558.0222...
-
Page 6: Device Layout
Rubber feet are also included for placement on a shelf/desk- top. Package Contents: (1) IMS-4010 Dry Contact Node w/Batteries installed (1) 9VDC Power Supply (1) CAT5 Ethernet Cable (1) DB9 Null Serial Cable... -
Page 7: Power Switch
6.75 Network Configuration The IMS-4010 Dry Contact Node has a serial port on the side which is used to configure network settings. A dumb terminal or terminal emulation software is required to get online and set up the configuration. The port is male DTE, so a DB9 female–female null modem cable will be required. - Page 8 To get online with the device, connect your terminal to the serial port and press <RETURN>. A menu will appear which will guide you through the setup. Sensaphone IMS-4000 Node Unit Version: 1.4.7 Main Menu 1. Display Network configuration 2. Configure Network settings 3.
-
Page 9: Battery Backup
Programming The IMS-4010 Dry Contact Node will appear in the IMS-4000 ConsoleView Software as a Node device below the Host. Refer to the IMS-4000 User's Manual for sensor programming instructions. Battery Backup The Dry Contact Node is designed to use rechargeable batteries only. -
Page 10: Specifications
32° to 122° F (0° to 50° C) Operating Humidity 5 to 90 % RH non-condensing Power Consumption 2.5W Power Requirements IMS-4010 120VAC 60Hz/9VDC 300mA (min) Power Supply 90-260VAC 50/60Hz 300mA (min) Multi-plug Power Supply IMS-4010-INT Battery Backup Four AA NiMH Rechargeable Batteries, 2000mAHr or higher... - Page 11 Returning an IMS Unit for Repair In the event that any of your Sensaphone IMS-4000 units do not function properly, we suggest that you do the following: 1) Record your observations regarding the individual unit’s malfunction. 2) Call the Technical Service Department at 610.558.2700 prior to sending the unit to Sensaphone for repair.
