Summary of Contents for Sensaphone IMS-4010E
- Page 1 SENSAPHONE ® IMS–4000 ™ IMS-4010E Dry Contact Node User’s Manual SENSAPHONE ® LIT-0172...
- Page 2 Every effort has been made to ensure that the information in this document is complete, accurate and up-to-date. Sensaphone assumes no responsibility for the results of errors beyond its control. Sensaphone also cannot guarantee that changes in equipment made by other manufacturers, and referred to in this manual, will not affect the applicability of the information in this manual.
- Page 3 • Read and follow all warning and instruction labels on the product itself. • To protect the IMS-4010E from overheating, make sure all openings on the unit are not blocked. Do not place on or near a heat source, such as a radiator or heat register.
-
Page 4: Year Limited Warranty
THIS LIMITED WARRANTY CONTAINS SENSAPHONE’S STANDARD TERMS AND CONDITIONS. WHERE PERMITTED BY THE APPLICABLE LAW, BY KEEPING YOUR SENSAPHONE PRODUCT BEYOND THIRTY (30) DAYS AFTER THE DATE OF DELIVERY, YOU FULLY ACCEPT THE TERMS AND CONDITIONS SET FORTH IN THIS LIMITED WARRANTY. - Page 5 State of Delaware, without regard to the principles of conflicts of law. Effective date 04/01/2009 PHONETICS, INC. d.b.a. SENSAPHONE 901 Tryens Road Aston, PA 19014 Phone: 610.558.2700 Fax: 610.558.0222...
-
Page 6: Power Switch
1 stop bit. A DB9 female–female null modem cable is required to configure the network settings. RJ-45 10/100BASE-T ETHERNET PORT This jack is for connecting to your network so that the IMS-4010E Dry Contact Node can communicate with the IMS-4000E Host. Two LEDs are provided to indicate Link Status (green) and Receive Data status (yellow). -
Page 7: Dip Switches
NETWORK CONFIGURATION The IMS-4010E Dry Contact Node has a serial port on the side which is used to configure network settings. A dumb terminal or terminal emulation software is required to get online and set up the configuration. The port is male DTE, so a DB9 female–... - Page 8 100Mbps. An Auto setting is also available which will attempt a full duplex connection, however, this may not be compatible with certain network hubs/switches. PROGRAMMING The IMS-4010E Dry Contact Node will appear in the IMS-4000E ConsoleView Software as a Node device below the Host. Refer to the IMS-4000E User’s Manual for sensor programming instructions.
-
Page 9: Battery Backup
2lbs (.9kg) RETURNING AN IMS UNIT FOR REPAIR In the event that any of your Sensaphone IMS-4000E units do not function properly, we suggest that you do the following: 1) Record your observations regarding the individual unit’s malfunction. 2) Call the Technical Service Department at 610.558.2700 prior to sending the unit to Sensaphone for repair.
