Summary of Contents for Sensaphone SAT4D
- Page 1 User’s ManUal version 3.2 LIT-0163 www.sensaphone.com...
- Page 2 Sensaphone assumes no responsibility for the results of errors beyond its con- trol. Sensaphone also cannot guarantee that changes in equipment made by other manufacturers, and referred to in this manual, will not affect the applicability of the information in this manual.
- Page 4 This product has been tested and found to be compliant for use in Hazardous Locations defined as Class I, Division 1, Groups A-D T4 The NRTL file number for the SAT4D is E113371. WARNING EXPLOSION HAZARD – BATTERIES MUST ONLY BE CHANGED IN AN AREA KNOWN TO BE NON-HAZARDOUS.
- Page 5 If you experience trouble with the SAT4D, or you need information on obtaining service or repairs, please contact:...
- Page 6 THIS LIMITED WARRANTY CONTAINS SENSAPHONE’S STANDARD TERMS AND CONDITIONS. WHERE PERMITTED BY THE APPLICABLE LAW, BY KEEPING YOUR SENSAPHONE PRODUCT BEYOND THIRTY (30) DAYS AFTER THE DATE OF DELIVERY, YOU FULLY ACCEPT THE TERMS AND CONDITIONS SET FORTH IN THIS LIMITED WARRANTY.
- Page 7 ARE INAPPLICABLE, THEN THE PURCHASER’S SOLE REMEDY SHALL BE PAYMENT TO THE PURCHASER OF THE ORIGINAL COST OF THE PRODUCT, AND IN NO EVENT SHALL WARRANTORS BE LIABLE OR RESPONSIBLE FOR PAYMENT OF ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL AND/OR PUNITIVE DAMAGES OF ANY KIND, INCLUDING BUT NOT LIMITED TO ANY LOST REVENUE, BUSINESS INTERRUPTION LOSSES, LOST PROFITS, LOSS OF BUSINESS, LOSS OF DATA OR INFORMATION, OR FINANCIAL LOSS, FOR CLAIMS OF ANY NATURE, INCLUDING BUT NOT LIMITED TO...
- Page 8 SAT4D User’s Manual WARRANTORS ASSUME NO LIABILITY FOR INSTALLATION OF THE PRODUCT AND/ OR INTERRUPTIONS OF THE SERVICE DUE TO STRIKES, RIOTS, FLOODS, FIRE, AND/OR ANY CAUSE BEYOND SELLER’S CONTROL, FURTHER SUBJECT TO THE LIMITATIONS EXPRESSED IN ANY LICENSE AGREEMENT OR OTHER AGREEMENT PROVIDED BY WARRANTORS TO PURCHASER.
-
Page 9: Table Of Contents
Table of Contents Table of ConTenTs CHApTER 1: INTRODUCTION ....11 Summary of feaTureS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 TeChniCal SupporT . - Page 10 SAT4D User’s Manual...
-
Page 11: Chapter 1: Introduction
When an alarm condition occurs the SAT4D can contact up to 8 people using its synthesized voice technology and can also send up to six e-mail or text messages. The SAT4D will send a status report twice a day to the website which includes the status of its four inputs and its location. -
Page 12: Technical Support
TECHNICAL SUppORT This User’s Manual will help you install and understand the opera- tion of the SAT4D. Be sure to read it completely before beginning the installation process. If there are any questions or problems that arise upon installation or operation, please contact our Technical Support team at: SENSAPHONE®... -
Page 13: Chapter 2: Installation
ENCLOSURE MOUNTING The SAT4D enclosure must be mounted so that it has a clear, unobstructed view of the sky. DO NOT mount the enclosure on its side, against the side of a building, or under a tree. These will all interfere with the unit’s ability to communicate with the satellite. -
Page 14: Installation Using The Pole Kit (Optional)
Fig 1. SAT4D Mounting Location . INSTALLATION USING THE pOLE KIT (OpTIONAL) 1) Locate an area where you will be installing the SAT4D. Make sure you can drive a pipe at least 3’ into the ground without dis- turbing any electrical wires, gas pipes, water pipes, telephone or cable wires, etc…... -
Page 15: Zone Input Wiring
Normally Open or Normally Closed. A dry contact is any open or closed circuit that has no volt- age applied (such as a relay or switch). The SAT4D will sense when the circuit changes from closed to open or vice-versa and then act accordingly. -
Page 16: Configuring The Input Normality
SAT4D User’s Manual ZONES Multiple normally-closed sensors wired in series (example using Input 2) Alert condition occurs when a switch is opened Multiple Normally Closed Sensors CONFIGURING THE INpUT NORMALITY Each Zone Input must be configured as either Normally Open or Normally Closed. -
Page 17: Configuring The Alarm Recognition Time
Chapter 2: installation CONFIGURING THE ALARM RECOGNITION TIME Set the Alarm Recognition Time for each zone input by setting the DIP Switches according to the table below. Switch A Switch B 3 seconds 1 minute 5 minutes 10 minutes TESTING THE SYSTEM Check that all equipment being monitored is operating normally and press the Alarm Status pushbutton. -
Page 18: Chapter 3: System Programming
SENSAPHONE® • 901 Tryens Road • Aston, PA • 19014 • PH: 877-373-2700 • F: 610-558-0222 • www.sensaphone.com The website allows you to view Status and Alarm Messages, as well as program your device. - Page 19 Chapter 3: System programming If you’d like to have alarm messages (SMS) sent to your cell phone, en- ter your telephone number along with the appropriate e-mail suffix for your carrier (shown below) into one of the six e-mail address program- ming fields.
-
Page 20: Chapter 4: Operation
SAT4D User’s Manual ChapTer 4: operaTion SATELLITE COMMUNICATION AND ALARMS When an alarm is detected the SAT4D will transmit the alarm message multiple times to the Satellite. The time between transmit attempts will vary randomly between 5 and 10 minutes to ensure that the message is received. - Page 21 To view the message history and unit location information for a particular SAT4D device, click on the Unit Name or Serial Number. The Map page shows the location of the SAT4D and all messages received from it. Each message includes the date and time the mes- sage was sent and the status of each of the zone inputs (OK, Alarm, or Cleared).
-
Page 22: Battery Information
The Satellite transmitter operates from (4) 1.5V AA lithium bat- teries which will last 3+ years. The Input board uses a single 3.6V AA Lithium battery (special) that will last 7+ years. The SAT4D website indicates the battery condition of the Satellite Transmitter. -
Page 23: Sample Alarm Messages
Note that all e-mail and text messages will be sent out simultane- ously as soon as the alarm is received at the SAT4D website. Voice calls, will be made one at a time. Up to three call attempts will be made per user. -
Page 24: Programming Changes
SAT4D User’s Manual pROGRAMMING CHANGES On the SAT4D website, simply click on the link to “Edit Programming” from the top of the Map page and you can change most of the SAT4D’s configuration details. Simply make your changes and click on the Save Setting button at the bottom of the... -
Page 25: Appendix A: Test Procedure
SAT4D. 4.) Keep a log of your tests, noting the date and whether the SAT4D passed in each category tested. An example of such a log is shown below. (See “Test Log” at the end of this manual.) -
Page 26: Appendix B: Accessories
SAT4D User’s Manual appendix b: aCCessories The sensors listed below are available from Sensaphone and rep- resent the most commonly used devices. Other dry contact sen- sors, designed for more specialized applications, may also be used. Commercial or industrial electrical supply houses can provide devices to monitor virtually any condition. -
Page 27: Appendix C: Specifications
appendix C: Specifications appendix C: speCifiCaTions ALERT ZONES Number of Zones: 4 Zone Connector: terminal block Zone Types: N.O./N.C. Contact Zone Characteristics: 3.3MΩ to 2.5V Zone Protection: 8VDC Metal Oxide Varistor with fast acting diode clamps. LED STATUS INDICATORS Number of LEDs: 4 Operation: Active while Alarm Status button is depressed. -
Page 28: Environmental
SAT4D User’s Manual ENVIRONMENTAL Operating Temperature: -22° to 140°F (-30° to 60° C) Normal, -40° to 185°F (-40° to 85° C) with battery life impact pHYSICAL Enclosure Dimensions: 11.3”(w) x 13.3”(l) x 5.6”(h) 28.7 x 33.7 x 14.22cm Enclosure Weight: 7lbs (3.7kg) Enclosure Specifications: NEMA 4X, UL508, IEC529, IP66 CSA C22.2 No. -
Page 29: Appendix D: Returning The Unit For Repair
The UniT for repair In the event that the SAT4D does not function properly, we suggest that you do the following: 1) Record your observations regarding the SAT4D’s malfunction. 2) Call the Technical Service Department at 610-558-2700 prior to sending the unit to Sensaphone for repair. -
Page 30: Appendix E: Test Log
SAT4D User’s Manual appendix e: TesT log Alarms... - Page 31 appendix e: Test log Alarms...
- Page 32 SAT4D User’s Manual...
