C a l i p e r B r a k e P a d R e m o v a l
1 Clamp the bicycle into a bicycle work stand and remove the wheel.
2 Remove the E-clip from the pad retention bolt.
2.5 mm
Remove the pad retention bolt from the caliper.
Needle Nose Pliers 15 mm Thru Axle
3 Remove the brake pads and pad H-spring from the caliper.
NOTI CE
If the brake pad thickness is less than 3 mm then replace the pads.
Digital Caliper

Caliper Brake Pad Removal

8
