User Alarm Mode

If the alarm system detects that the park brake has been disengaged while at least one jack is not fully retracted and
the sensor value changes in any axis more than a predefined amount, the panel will signal this error to the user.
The system performs an automatic retract.
No other features are available in this mode.

Miscellaneous

A. The leveling system will automatically shut off after being idle for 4 minutes.
B. Auto leveling cycle cannot be started until all jacks are fully retracted. Make sure jacks are
retracted before attempting to auto level (unit will perform full retract automatically if jacks are
down on the request of an auto cycle).
C. System will refuse any operation when a low voltage condition is present.
D. System will automatically alarm and retract if park brake is disengaged and jacks are not retracted
with any change in sensor readings. In alarm mode, the only available feature is to retract all jacks.

Low Voltage Signal

A. The vehicle requires 12.75V DC to operate in the AUTO mode. If the voltage is too low, the screen
will display "LOW VOLTAGE".
B. Minimum Voltage - If voltage drops below 9.5V DC during AUTO or MANUAL operation, "LOW
VOLTAGE" will appear in the screen and the system will cease operating.
NOTE: Coach will operate in manual mode between 9.5V DC and 12.75V DC.

Operation

Selecting A Site

When the coach is parked on an excessive slope the leveling requirements may exceed the jack lift stroke capability.
If the coach is parked on an excessive slope, the coach should be moved to a more level surface before the leveling
system is deployed.
"EXCESS ANGLE" will appear on the LCD screen if the coach is 3.5° out of level front to rear or side to side. See error
code chart on Page 10.

Automatic Leveling Procedure

NOTE: Refer to Component Description, page 4 and Fig. 5, page 7 for questions regarding location and
functions of the LCI Level-Up Motorhome Leveling System for Winnebago Industries system.
NOTE: Coach must be running and parking brake must be engaged for LCI Level-Up Motorhome Leveling
System for Winnebago Industries to operate.
1. Push "On/Off" button to turn system "On" (Fig. 5K).
2.
Push "Auto Level" button (Fig. 5F).
3.
The coach will level automatically and indicate "Auto Level - SUCCESS!" in LCD display (Fig. 5E).
NOTE: Display will then read "LEVEL - Jacks: Down". Do not press any buttons until this message appears or
a "FUNCTION ABORTED" error will be displayed.
NOTE: In cold weather operation, always check to make sure all jacks, slide rooms, steps are fully retracted
before travel.
Rev: 12.27.2017 Page 11
