System Description

Please read and study the operating manual before operating the leveling system.
The LCI Level-Up Motorhome Leveling System for Winnebago Industries is an electric/hydraulic system. A
12V DC electric motor drives a hydraulic pump that moves fluid through a system of hoses, fittings and jacks
to level and stabilize the coach.
Mechanical portions of the LCI Level-Up Motorhome Leveling System for Winnebago Industries are
replaceable. Contact Lippert Components, Inc. to obtain replacement parts. See Page 19 for the Bill Of
Materials list.

Component Description

1. Jacks
A. Rated at a lifting capacity for your coach.
B. 9" diameter (63.5 square inch) footpad on a ball swivel for maximum surface contact on all
surfaces.
C. 12" diameter - 113 square inch footpad also available.
D. Powered from a 12V DC Motor/Pump assembly.
2. Motor/Pump Assembly
A. 12V DC Motor
B. Hydraulic oil reservoir tank
C. Control Valve Manifold
D. Solenoid Valves
3. System Controls
A. Controlled electronically from the driver's seat of the coach.
B. Touch Pad is mounted in the dash or side console.
C. Touch Pad can be operated in manual mode or fully automatic mode.

Maintenance

Fluid Recommendation

The LCI Level-Up Motorhome Leveling System for Winnebago Industries is pre-filled, primed and ready to
operate direct from Winnebago Industries:
PetroBlend (Mason City, IA), PHO 0022S (group 3 base blend).
NOTE: In colder temperatures (less than 10° F) the jacks may extend and retract slowly due to the fluid's
molecular nature. For cold weather operation, fluid specially formulated for low temperatures may
be desirable. Please consult fluid specifications on Page 16.

Preventative Maintenance

1. Check fluid in reservoir every 12 months. If fluid is a clear, red color, do not change. If fluid is milky, pink
and murky, and not clear red in color, drain reservoir and add new fluid. Use recommended fluid (see
Page 16).
NOTE: Check fluid only when all jacks are fully retracted.
NOTE: When checking fluid level, fill to within ¼ to ½ inch of fill spout.
2.
Inspect and clean all Power Unit electrical connections every 12 months. If corrosion is evident, spray
unit with lubricant.
3.
Remove dirt and road debris from jacks as needed.
Rev: 12.27.2017 Page 4
