"Jacks Down" Alarm

The LCI Level-Up Motorhome Leveling System for Winnebago Industries is designed to sound an alarm and
illuminate the control panel in the event of two (2) possible scenarios:
1.
A "RETRACT" hose leaks.
2. The pressure holding the jacks in the retracted position falls to approximately 1500 psi.
NOTE: If you should happen to hear the "Jacks Down" alarm:
3.
Immediately find an area to safely pull the vehicle off of the roadway.
4. Set the PARKING BRAKE.
5.
Inspect all jacks, hoses and valves for leaks.
NOTE: If no leaks are observed; Turn control panel "ON."
6. Push "RETRACT ALL JACKS" button.
7.
Wait until "JACKS DOWN" light and alarm are off.
8.
Inspect jacks. If jacks are retracted and no leaks are observed, vehicle can be driven.
NOTE: If system is leaking or alarm does not subside after applying the above procedure, disconnect wires
from pressure switch and proceed immediately to a service center. The pressure switch is a blue and
gold colored valve located on the power unit manifold identified by the deutsch connector with
yellow and black wires. See wiring digram on Page 17 for location of pressure switch.
NOTE: For prolonged travel to the service center, be sure to stop and check the disposition of the leveling
jacks every so often to make sure they are not extending.

Fluid Recommendation

The Lippert Electronic Leveling System is pre-filled, primed and ready to operate direct from the manufacturer.
Type "A" Automatic Transmission Fluid (ATF) is utilized and will work. ATF with Dexron III® or Mercon 5® or a blend
of both is recommended by Lippert Components, Inc.
In colder temperatures (less than 10° F) the jacks may extend and retract slowly due to the fluid's molecular nature.
For cold weather operation, fluid specially formulated for low temperatures may be desirable. For a list of approved
fluid specifications, see TI-188.
Rev: 12.27.2017 Page 16
