Fitting Orientation

NOTE: Fittings - High pressure O-Ring Face - Size 4
¼
NOTE: Hose - in. I.D. 3000 psi - W.P. Rated
Callout
A
B
C
D
E
F
Rev: 12.27.2017
A
E
B
F
C
Part #
177094 / 174184
142927
--
156846 / 141109 (Straight)
140457 / 320521 (Elbow)
156846 / 143108
Fig. 4
E
D
Description
Valve/Coil - Rear Jacks
Pressure Switch
Filler Vent
Extend Fittings
Fittings are labeled w/ port assignments
found stamped into the manifold.
Quick Disconnect for Flush & Fill
Return Fittings
Page 6
