CNY8:
Backlight Control
See JP7 and JP8 to set the
Backlight Power voltage and
Panel Power voltage.
6.11 Keyboard & Mouse
CN4:
Mouse (top)
Keyboard (bottom)
Express-BASE User's Manual
Pin
Signal
1
GND
1
3
Backlight CTRL
5
Backlight Enable 6
7
7
BLCTL
6
5
4
3
2
1
6
5
4
3
2
1
Pin
Signal
2
Panel PWR
4
GND
GND
8
Backlight PWR
Pin
Signal
1
MSDAT
2
NC
3
GND
4
KB5V
5
MSCLK
6
NC
Pin
Signal
1
KBDAT
2
NC
3
GND
4
KB5V
5
KBCLK
6
NC
