7.5
Digital I/O LEDs
Express-BASE User's Manual
LEDX1 - LEDX8 are indicators for the
Digital I/O Connector CNY2. When the I/O
signal is high, the LED will light. The I/O 0
signal corresponds to LEDX1, and the I/O 7
signal corresponds to LEDX8.
Page 37
