4. Convenience features

HOW TO DATA COMMUNICATION

Connections for data communication
1 Insert the Data Communications card (sold separately) into the PC
card slot.
2 Carefully check the orientation of the interface connector on the
connection cable (sold separately), and then insert it into the card
while pressing the lock buttons on the sides.
3 Open the cover of data communications terminal on the telephone,
and plug the connector securely into it while pressing the lock but-
tons on the sides of the connector.
• To remove the cable and PC card, fol-
low the above procedure in reverse.
• After you plug the connector into the
telephone, the following message will
be displayed, and the telephone will
make a beep (Pi-Po) sound (unless the
ringer volume is turned off).
Page 80
• When you remove the cable con-
nector from the phone, the follow-
ing message will be displayed,
and the telephone will make a
beep (Pi-) sound (unless the
ringer volume is turned off).
80

TRANSMITTING DATA

1 Transmitting data from a personal computer connected to the data
communications terminal.
• For information about the procedure, refer to the instruction manuals for the
data communications card and the communications software.
• If the connection is broken from the other end first, the telephone will sound a
warning (suu suu .. .. ..), and return to standby mode after 10 seconds.
NOTE
• Using the telephone in areas where there is a lot of electromagnetic radiation
can result in broken connections.
• Do not move the telephone during transmission. This can cause broken con-
nections.
• The dial information in the case of data transmission is not stored in the tele-
phone's redial memory.
• Long communication
Ensure that the telephone battery is sufficiently charged. To conserve battery
power, it is also possible to transmit from the telephone while it is seated on the
charger.
• Connection to personal computers
Even if you are not transmitting or receiving, the standby time on battery power
is reduced. Also, depending on the data communications card that you are
using, battery power may be consumed even if the telephone is switched off.
For this reason, if you do not plan to perform data communication for a time,
disconnect the communication cable from the telephone.
• Lock Phone
When Lock PHone is set, it is not possible to switch to transmission or commu-
nication mode from the personal computer.
4. Convenience features
81
