User Manual
Ascom Myco Wi-Fi and Cellular Smartphone
• Refer to
are shown in the top display.
3.1.9

Ascom IR location

The Ascom Myco handset is capable of using IR-positioning with the Ascom IR Location
feature.

3.1.10 Color Pad for Clip

The color pad on top of the clip is used to differentiate the handsets between, for example,
workgroups, shifts, or roles. The blue color pad is attached by default, and it can be
exchanged for one of the colors, red, yellow, or green. See
Hinge-Type Clip
3.2

Accessories

The following accessories are available for the handset:
Battery Pack
Spare clip
Safety cord
Color pad kit for clip
CR5 Charging Rack
CR6 Battery Charging Rack The Battery Charging Rack(CR6) charges up to six Battery
Table adapters for
Charging Rack (CR5/CR6)
Micro-USB cable
USB Power supply
Headset with mic on cable
Headset adapter (3.5
b
mm)
a.Only available for Ascom Myco 2.
b.Only available for Ascom Myco 2.
1.Only available for Ascom Myco 2.
3 October 2017 / Ver. H
3. Handset Description
11.2 Color-Coded LED Signals
1
on page 80.
A replacement Battery Pack may be replaced and charged
separately in the Battery Charging Rack, which is the quickest
way to charge.
The replacement hinge-type clip is especially designed to fit
one-layered fabric, such as shirt pockets.
The Safety Cord is attached around the clip to prevent from
dropping the handset.
The color pad is attached to the clip, and is used to easily
identify the handset belonging to, for example, a workgroup,
shift, or role.
The Charging Rack (CR5) charges up to six handsets at the
same time.
Charging time (fully depleted battery): Approx. 4 hours.
Packs at the same time.
Charging time (fully depleted battery): Approx.3 hours.
With the attachable feet the Charging Rack can be placed on a
table, instead of being wall mounted.
The Micro-USB cable, attached to the USB Power supply,
charges one handset at a time, for example at your own desk.
When connected to (an active) computer, the USB cable can
also be used to charge the handset, or for troubleshooting.
Charging time (fully depleted battery): Approx. 4.5 hours.
The USB Power supply is used with the Micro-USB cable, for
charging in a wall socket.
a
With an Ascom headset adapter, the Ascom headset can be
used for hands-free calling.
The headset adapter plugs into the Charging-/Headset
connector. Once connected, it accepts any 3.5 mm Android
compatible headset, including the Ascom original headset.
on page 63 for details on how other notifications
18.3 Replace the Color Pad for the
