User Manual
Ascom Myco Wi-Fi and Cellular Smartphone
Figure 24. Alerts labeled with category colors.
The following category colors are available:
• Red
• Green
• Blue
• Yellow
• Orange
• Cyan
• Purple
• Pink
• Dark Red
• Brown
• Grey
• White
• Black
The red and dark red category colors both show as the same red color on the LED alert
beacon. Brown, grey and black are shown as white on the LED alert beacon, unless a crisis
priority (1) is received, in which case the beacon flashes red.
NOTE: The category colors are dependant on configuration, and can differ between system
setups. Contact your site administrator for details about the use of category colors at
your site.
7.3.3

Alert Type Icons

The alert type icons indicate the alert type, for example a nurse call, or a lab result
notification.
The following are examples of alert type icons that can be used at a site:
Icon
3 October 2017 / Ver. H
7. Alerts
Alert Type
Assistance call
Category A
Category B
TD 93066EN
52
