Chapter 2 — Configuring Network Settings
Ethernet Settings Descriptions
Parameter
Enable DHCP
IP Address
IP Subnet
IP Router (Gateway)
Link Local IP Address
IPv6 Autoconfigure
IPv6 Address
IPv6 Router
22
3 Click Activate Changes to save your changes and immediately
make them active.
Description
Check this check box if you want the IF2 to get its IP address from a
DHCP server.
If this check box is not checked, you need to specify the IP address,
subnet mask, and IP router for your network.
IP address of the IF2. The IP address has the form x.x.x.x, where x is a
number from 0 to 255.
If DHCP is enabled, the currently assigned IP address appears in this
field.
If DHCP is disabled, specify the IP address in the entry field.
Subnet mask for this network. The subnet mask has the form x.x.x.x,
where x is a number from 0 to 255.
If DHCP is enabled, the currently assigned subnet mask appears in this
field.
If DHCP is disabled, you may need to specify the subnet mask for the
network.
IP address of the router. The IP address has the form x.x.x.x, where x is a
number from 0 to 255.
If DHCP is enabled, the currently assigned router address appears in this
field.
If DHCP is disabled, you may need to specify the router address for the
network.
IP address of the IF2 is only routable on the local IP subnet. The IF2
auto-negotiates with other devices on its Ethernet segment to obtain a
unique address, so no user configuration of the Link Local IP Address is
necessary. The IF2 will always have a Link Local IP Address, even if
another address is assigned through DHCP or statically via user-
configuration.
Enables IPv6 automatic configuration. Clear this check box to disable
IPv6 auto-configuration on the IF2.
Auto-configuration is enabled by default. If you disable auto-
configuration, you need to specify an IPv6 address, subnet mask, and
router.
128-bit IPv6 address for the IF2.
128-bit address for the IPv6 router.
