IP 2L
Snap-On LF/UHF RFID Reader
1000AA09
DRAFT
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP2L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec IP2L

Summary of Contents for Intermec IP2L

  • Page 1 IP 2L Snap-On LF/UHF RFID Reader 1000AA09 DRAFT User Guide...
  • Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2013 by Intermec Technologies Corporation. All rights reserved.

  • Page 3: Table Of Contents

    About the IP2L Snap-On LF/UHF RFID Reader ........
  • Page 4 Troubleshoot the IP2L........

  • Page 5: Before You Begin

    Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com and click Support > Returns and Repairs > Warranty.

  • Page 6: Send Feedback

    IP2L, and how to install, configure, operate, maintain, and troubleshoot it. Before you work with the IP2L, you should be familiar with your network and general networking terms, such as IP address. Related Documents Here are some related Intermec documents you may find useful: •...

  • Page 7: Patent Information

    Manuals. Use the Product Category, the Product Family, and Product to find your documentation. Patent Information Product is covered by one or more of the following patents: x,xxx,xxx; x,xxx,xxx; x,xxx,xxx. There may be other U.S. and foreign patents pending. DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 8 Before You Begin DRAFT viii IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 9 Before You Begin DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 10 Before You Begin DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 11: About The Ip2L Features

    About the IP2L Features This chapter introduces the IP2L for the CN70 and CN70e. Use this chapter to learn about the basic features and functions of the IP2L RFID reader. DRAFT...

  • Page 12: About The Ip2L Snap-On Lf/Uhf Rfid Reader

    Chapter 1 — About the IP2L Features About the IP2L Snap-On LF/UHF RFID Reader The IP2L snaps-on to the bottom of your CN70/CN70e mobile computer and provides a high-performance mobile RFID solution that allows you to read and write to RFID tags.

  • Page 13: What You Need

    Chapter 1 — About the IP2L Features What You Need Before you can read and write to RFID tags using the IP2L, make sure these items are installed on the computer: • the latest Microsoft Windows Mobile Operating System (OS) the latest Intermec firmware •...

  • Page 14: Connect And Enable The Rfid Reader

    Chapter 1 — About the IP2L Features Connect and Enable the RFID Reader Connect the IP2L and enable the RFID reader before you start reading and writing to RFID tags. 1 Connect the IP2L to the bottom of your mobile computer. The IP2L snaps into place.
  • Page 15 3 Tap RFID > Enable RFID Service and select Enable RFID Service. 4 Tap OK to save your changes. 5 Tap Reader Model. 6 Select IP2L Snap-on LF/UHF. 7 Tap OK to save your changes. The IP2L is connected and enabled. DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 16: Remove The Ip2L

    Chapter 1 — About the IP2L Features Remove the IP2L When you are done using RFID, remove the IP2L from the computer. • Press the two side release buttons together to remove the IP2L. DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 17: Charge The Computer Battery

    Charge the Computer Battery The IP2L is powered by the computer battery and can easily be charged when the IP2L is connected to the computer. Use one of the following charging accessories to charge computer battery when the IP2L is connected.

  • Page 18: About The Status Leds

    Chapter 1 — About the IP2L Features About the Status LEDs When the IP2L is connected and enabled, the status LEDs turn on, turn off, or blink to indicate RFID activity on your computer. Good Read LED Notification LED Battery status LED...

  • Page 19: Rfid Tag Read Positions

    Chapter 1 — About the IP2L Features RFID Tag Read Positions The IP2L can read and write to UHF tags up 18 in (45.1 cm) away and LF tags at 1 in (2.2 cm) away. The read range for UHF tags depends on the way you hold the computer when you attempt to read or write to a tag.
  • Page 20 Chapter 1 — About the IP2L Features UHF tag 30 cm (12 in) 30 cm (12 in) Read Range When Held In This Position. UHF tag 22.8 cm (9 in) 22.8 cm (9 in) Read Range When Held In This Position.
  • Page 21 Chapter 1 — About the IP2L Features UHF tag 15 cm (6 in) 15 cm (6 in) Read Range When Held In This Position. LF tag 2.2 cm (1 in) 2.2 cm (1 in) Read Range When Held In This Position.

  • Page 22: Read And Write To Rfid Tags

    Chapter 1 — About the IP2L Features Read and Write to RFID Tags Use this section to learn how to read or write to RFID tags. Before you start to read and write to RFID tags: • connect the IP2L to the computer.

  • Page 23: Create And Use Rfid Applications

    Create and Use RFID Applications This chapter explains how you can use RFID applications and configure the IP2L. DRAFT...

  • Page 24: Rfid Applications And The Ip2L

    PC). • Install and test the application on your computer. If you do not have an application but want to verify that your IP2L can read and write RFID tags, download the Intermec RFID Demo application from the Intermec website.

  • Page 25: Configure The Rfid Service Settings

    RFID reader. Set the TCP port to something else if the default is already being used. Enable Logging This logs all RFID activities when you are DRAFT troubleshooting the RFID reader. IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 26: Configure The Rfid Module Settings

    Choose from space ( ), comma (,), colon (:), semicolon (;), tab, caret (^), or tilde (~). Default is space. This setting is equivalent to the FIELDSEP BRI attribute. IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 27 DRAFT returned to a Write command. In practice, this is the number of times an identified tag is read until the Write is successful. This setting is equivalent to the WRTIES BRI attribute. IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 28 For example, if the tag is close to the antenna, full output power DRAFT might overload the tag and cause unreliable behavior. This setting is equivalent to the FIELDSTRENGTH BRI attribute IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 29 Chapter 2 — Create and Use RFID Applications RFID Module Settings Descriptions (continued) Setting Description Session Enable Antenna Port 1 DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...
  • Page 30 Chapter 2 — Create and Use RFID Applications DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 31: Troubleshoot The Rfid Reader

    Troubleshoot the RFID Reader This chapter explains how to troubleshoot the IP2L RFID reader. DRAFT...

  • Page 32: Call Product Support

    Chapter 3 — Troubleshoot the RFID Reader Call Product Support If you are having trouble using the IP2L or computer, you can: • use the troubleshooting tables in this manual to find your problem and possible solutions. visit the Intermec technical knowledge base, Knowledge Central at •...

  • Page 33: Troubleshoot The Ip2L

    The following table may help you fix some common problems you may experience while using the IP2L. Note: If you send the IP2L or computer in for service, it is your responsibility to save the computer data and its configuration.
  • Page 34 Chapter 3 — Troubleshoot the RFID Reader DRAFT IP2L Snap-On LF/UHF RFID Reader User Guide...

  • Page 35: About The Ip2L

    About the IP2L This appendix contains specifications for the IP2L RFID reader. DRAFT...

  • Page 36: Physical Specifications

    Humidity 5 % to 95% (non-condensing) RFID Specifications This section lists the RFID specifications for the IP2L. Supported LF tag types TI TIRIS at 134.2 kHz half duplex Supported UHF tag types Class 1 Gen 2 EPC (ISO 18000-6C) Frequency range* 902 to 928 MHz •...
  • Page 37 DRAFT...
  • Page 38 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 DRAFT www.intermec.com © 2013 Intermec Technologies Corporation. All rights reserved. IP2L Snap-On LF/UHF RFID Reader User Guide *123-456-789* P/N 123-456-789...
