NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS

DESCRIPTION OF THE NEXA MODULAR DOOR PANEL

Description of the door panel:
Door panel component assembly drawing.
Embedding box
INSTALLATION OF THE DOOR PANEL

Positioning the embedding box:

Make a hole in the wall to position the top of the door panel at a height of
Hole dimensions:
NCEV-90CS
The door panel has been designed to be used under most environmental conditions. It is however advisable to
take extra precautions to prolong its service life (shields, covered areas, etc.)
To obtain optimum video door entry system image quality, avoid direct contact from light sources (sunshine,
street lights, etc.) .
Frame module
Sound module
EL632 GB2A , video door entry system with colour television camera
1650
embedding box
Sound module
1850
1450
: 99(W) x 132.5(H) x 56.5(D) mm.
Aluminium panel
1.65m.
.
5
