NEXA MODULAR GB2 VIDEO DOOR ENTRY SYSTEM KIT - VILLAS

WIRING DIAGRAMS:

One-apartment kit (N5110 VESTA7 kit) and Golmar DC lock release.
Distances and
cross-sections:
VESTA7
B
Cable
Twisted pair 2x0.75mm
FA- GB /A 2
( ) 2
Twisted pair 2x1mm
( ) 2
Distances with Golmar RAP-2150 cable
A
(twisted pair 2x1mm ).
C
Configure the end of line in
*
the last monitor.
DIP 6 to ON.
Two-apartment kit (N5220 VESTA7 kit) and Golmar DC lock release.
Distances and
cross-sections:
VESTA7
VESTA7
B
Twisted pair 2x0.75mm
FA- GB /A 2
( ) 2
Twisted pair 2x1mm
( ) 2
A Distances with Golmar RAP-2150 cable
(twisted pair 2x1mm ).
C
* Configure the end of line in
the last monitor.
DIP 6 to ON.
( ) 1 Important: For AC lock releases or a second lock release, see diagram 'Connection of Golmar AC and DC lock releases' on p. 19.
APARTMENT
CODE 0
*
A B C
2
60m 60m 10m
2
80m 80m 15m
2
Lock release
max. 12 Vdc/270mA.
APARTMENT 2
VESTA7
CODE 16
*
BUS
Cable A B C
2
60m 60m 10m
2
80m 80m 15m
2
Lock release
max. 12 Vdc/270mA.
1
VESTA7
BUS
SW1
ON
1 2 3 4 5 6
_
+
C1 NA1 AP- AP+
Relay 1
12Vdc
( ) 1
APARTMENT 1
VESTA7
CODE 0
BUS
SW1
ON
1 2 3 4 5 6
_
+
C1 NA1 AP- AP+
Relay 1
12Vdc
( ) 1
Mains
100~240Vac
N L L
CN
FA- GB /A
Access panel
NA2 C2 AP+ AP- P1 P2 BUSBUS
Relay 2
( ) 1
AP
Mains
100~240Vac
N L L
CN
FA- GB /A
Access panel
NA2 C2 AP+ AP- P1 P2 BUSBUS
Relay 2
( ) 1
AP
12
2
BUS (M) BUS(PL)
2
BUS (M) BUS(PL)
