M o d e l 2 0 0 9
7.3 Dispensing cups/mugs
1. Place an empty cup under the outlet (¿ g. 29).
2. Make your selection .
3. Your selection will be prepared [ One moment ].
4. Your drink is ready when the display shows the
text: [ Make your choice . . . ]
7.4 Dispensing jugs
The macinhes TS, TL and HS can fill thermos jugs.
1. Place an empty jug under the outlet (fig. 30).
2. Turn the jug lock (optional) to the right.
3. Make your selection .
4. Your selection will be prepared [ One moment ].
Attention: coffee preparation progress is
indicated on the display. The coffee is made
and poured into the jug per cup.
Emergency stop: The dosing of a Jug recipe
can be stopped by simply pressing any button.
The selected recipe is then cancelled and one
more cup is dispensed.
5. Your drink is ready when the display shows the
text: [ Make your choice . . . ]
6. When you are ¿ nished, turn back the jug lock and
retrieve the key.
Jug lock (optional)
If the machine is equipped with an optional jug lock,
only the person who has the key, has the possibility to
dispens a jug (fig. 30).
Cups tray
Pull the Cups tray (fig. 31) forward.
74 08/2011 Rev. 7.4
7.5 Payment system (optional)
7.5.1 Coin system
Major parts (¿ g. 32):
1. Coin acceptor slot
2. Returns button
3. Money return slot
4. Money tray
5. Door lock is also money tray lock
Set to paid
1. Open the operator menu (see chapter 6).
2. Go to 1.0 Free vend.
Fig. 29 3. Change Yes into No and con¿ rm your choice.
4. The machine is now set to paid dispensing.
[ Make your choice and insert exact money ]
Set to free
1. Open the operator menu (see chapter 6).
2. Go to 1.0 Free vend.
3. Change No into Yes and con¿ rm your choice.
4. The machine is now set to free dispensing.
[ Make your choice ]
Using paid vending
See ¿ g. 33
1. Place a cup (select the desired drink if price is
unknown). The display shows the price of
Fig. 30
your drink on the left and the inserted amount on the
right (Cr.).
2. Insert the correct change.
3. Make you choice
4. Your drink is prepared.
For setting / changing product prices, see chapter
2.3 Service menu in the service book or contact your
dealer.
Fig. 31
08/2011 Rev. 7.4
M o d e l 2 0 0 9
1
2
3
4
5
75
Fig. 32
Fig. 33
