2.4 Tables

TABLE 1 Capacity information Optivend 1TS, 1TL, 3TS, 4TS - 3200W
Dosing coffee Dosing time Number at ones
Sec. Jug
2x120ml 12 11
1,2 liter 50 2
1,5 liter 60 2
2,0 liter 80 1
2,2 liter 90 1
TABLE 2 Capacity information Optivend 1TS, 1TL, 3TS, 4TS - 6400W
Dosing coffee Dosing time Number at ones
Sec. Jug
2x120ml 12 240
1,2 liter 50 73
1,5 liter 60 53
2,0 liter 80 44
2,2 liter 90 40
TABLE 3 Capacity information Optivend High Speed - 9600W
Dosing coffee Dosing time Number at ones
Sec. Jug
1 x 240ml 9 400
1,2 liter 40 90
1,5 liter 50 72
2,0 liter 66 54
2,2 liter 72 50
TABLE 4 Capacity information Optivend High Speed DUO - 9600W
Dosing coffee Dosing time Number at ones
Sec. Jug
2 x 120ml 12 -
1 x 1,5 liter 80 45
2 x 1,5 liter 102 70
Recovery time max. dosing
Cup Sec.
22 4
24 80
25 95
16 125
18 138
Recovery time max. dosing
Cup Sec.
480 -
730 -
662 -
733 -
733 -
Recovery time max. dosing
Cup Sec.
800 -
900 -
900 -
900 -
916 -
Recovery time max. dosing
Cup Sec.
600 -
562 -
875 -
56 08/2011 Rev. 7.4
M o d e l 2 0 0 9
TABLE 5
Ingredient Dimension Volume Instant
Coffee 500 gr.
Topping 1000 gr.
2,3 ltr
Chocolate 1600 gr.
Sugar 2000 gr.
Coffee 1200 gr.
Topping 2200 gr.
5,1 ltr
Chocolate 3400 gr.
TABLE 6
Model Empty
OptiVend CHOCO 16,2
OptiVend 1 16,2
OptiVend 2 16,5
OptiVend 3 22,3
OptiVend 4 22,3
OptiVend 1 TS 23,0
OptiVend 1 TL 24,4
OptiVend 3 TS 24,6
OptiVend 4 TS 25,0
OptiVend HS
OptiVend HS DUO
OptiVend HS DUO Cappuccino #
* = full ingredient holders and boiler
# = Optional model
TABLE 6a
To reach
Model operating
temperature
OV choco, 1 & 2 212
OV 3, 4, 1 TS, 1 TL,
3 TS, 4TS, HS, HS 433
DUO
1 2
without dispensing / dispensing of 200ml coffee each 30 minutes /
08/2011 Rev. 7.4
Capacity ingredient canisters
Cups/120ml OptiVend model
360 cups 2 / 4
- 2 / 3 / 4
80 cups 2 / 3 / 4
- 4
860 cups 1 / 3 / HS / HS DUO
-
170 cups 1
Weights (kg)
Filled* incl. packaging
21,7 19,0
19,5 19,0
18,4 19,3
31,3 25,9
32,4 25,9
29,5 26,6
31,0 28,0
33,6 28,2
35,1 28,6
Power consumption [Wh]
Operating Operating For each hour
1 2
mode mode stand by
53 100 42
91 127 57
3
boiler kept warm on 60°C
57
3
