RLX2 Industrial Hotspot Series

Radio Status

The general radio status fields appear at the top of the Radio Configuration window.
Note: Different versions of the RLX2 Radios support different functionality. There may be more or
fewer options on this page, depending on the version of the radio.
Use the settings in the Radio Status panel to view the current settings for this radio.
Field
Radio Name
Radio MAC
Radio Type
Firmware
Update every
Up Time
Link Time
Signal Strength
Parent MAC
Page 72 of 212
Description
The user assigned name of the radio.
MAC address of the selected radio. The MAC ID is also printed on the side of
the radio.
The Model Number of this radio –Examples: RLX2-IHA, RLX2-IHG, RLX2-IHNF,
or RLX2-IHW.
Version of firmware currently installed. All radios on the network must have
the same firmware versions installed to guarantee proper operations. For
more information on firmware versions, refer to Update firmware (page 132).
Value in seconds controls how often the web configuration form
automatically refreshes. To change the value temporarily, enter the new value
and press the [Tab] key. To change the value permanently, enter the new
value and press the [Enter] key.
The length of time the radio has operated since the last system power-up or
last system reset.
The length of time that the radio has been continuously connected to parent
radio.
Strength of the signal from the Parent radio.
MAC address of the parent radio to which the selected radio is linked.
