RLX2 Industrial Hotspot Series
WARNING: Do not connect or disconnect the PoE connection when energized.
Antennas are to be installed in accordance with Control Drawing 06/2514.

For RLX2-IHNF-WC Radios

This radio is suitable for Class I, DIV2 hazardous locations.
This radio contains a set of wires that protrude through a single conduit hub. One wire
is terminated with an RJ45 connector for Ethernet connections. This wire can also
supply power if attached to a PoE Injector.
The second wire supplies power to the radio if a PoE Injector is not used. If not using
these cables, simply terminate them.
To install this radio....
1. Place a Seal Cap over the top of the conduit.
2. Run both wires down through the conduit.
3. Push the conduit up into the permanently installed connector on the bottom of the
radio. Push it up as far as it will go.
