FCC Emission Regulations

The following charts show the maximum emissions allowed for the FCC in the United
States. These data should only be considered guidelines. Consult official FCC documents
for the latest official regulations.
In the 2.4 GHz band, the maximum Equivalent Isotropically Radiated Power (EIRP) is 4W
for multipoint links: that is, radios with omnidirectional antennas. Point-to-Point links
using directional antennas are allowed higher EIRP.

2.4 GHz Band, Point-To-Multipoint

Maximum Power From Radio
dBm
30
27
24
21
18
15
12

2.4 GHz Band, Point-To-Point

Maximum Power From Radio
dBm
30
29
28
27
26
25
24
23
22
ProSoft Technology, Inc.
June 15, 2015
Maximum Antenna
Gain
mW dBi
1000
500
250
125
63
32
16
Maximum Antenna
Gain
mW dBi
1000
800
630
500
400
316
250
200
160
RLX2 Industrial Hotspot Series
Maximum EIRP
dBm
6 36
9 36
12 36
15 36
18 36
21 36
24 36
Maximum EIRP
dBm
6 36
9 38
12 30
15 42
18 44
21 46
24 48
27 50
30 52
W
4
4
4
4
4
4
4
W
4.0
6.3
10.0
16.0
25.0
39.8
63.0
100.0
158.0
