RLX2-IHW Detailed Specifications

Radio
Frequency Band
(Varies by country)
Wireless Standards
Transmit Power (Programmable)
(varies by country)
Channel data rates (Modulation)
Receiver Sensitivity (Typical)
Channels Selection
Security
Physical
Enclosure
Size
Vibration
Shock
Ethernet Ports
Antenna Ports
Weight
Environmental
Operating Temperature
Humidity
ProSoft Technology, Inc.
June 15, 2015
802.11b/g:
2.412 GHz to 2.462 GHz (FCC)
2.412 GHz to 2.472 GHz (ETSI)
802.11a:
5.150 GHz to 5.250 GHz (FCC/ETSI)
5.725 GHz to 5.850 GHz (FCC)
802.11a, 802.11b, 802.11g, 802.11i
Up to 50 mW without amplifier
Up to 500 mW with optional amplifier. (not applicable
for hazardous locations)
802.11b: 11, 5.5, 2, 1 Mbps
(DSSS - BPSK, QPSK, CCK)
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps (OFDM)
-90 dBm @ 1 Mbps
-85 dBm @ 11 Mbps
-82 dBm @ 24 Mbps
-75 dBm @ 54 Mbps
1 to 13 (802.11b/g)
36, 40, 44, 48, 149, 153, 157, 161, 165 (802.11a)
WPA2 - 802.11i with 128 bit AES-CCM
Legacy WPA TKIP, WEP support
MAC ID filter
Admin password
Extruded aluminum with DIN and panel mount
14.8 x 11.8 x 3.8 cm (H x W x D)
5.82 x 4.64 x 1.48 in (H x W x D)
IEC 60068 2-6 (20g, 3-Axis)
IEC 60068 2-27 (5g, 10 Hz to 150 Hz)
One 10/100/1000 Base-T connector, shielded RJ45
(2) RP-SMA connectors
1.06 lbs (479g)
-40°C to +75°C (-40°F to +167°F)
Up to 100% RH, with no condensation
