RLX2 Industrial Hotspot Series
Approved Antenna Table
Use the following approved antennas when the radio module is connected directly to an
antenna. Refer to Approved antennas with power amp for a table of approved antennas
with bi-directional power amplifiers.
Type
1/2 Wave
1/2 Wave art.
Collinear Array
Collinear Array, art.
Collinear Array
Collinear Array
Collinear Array
Collinear Array
Patch
Patch
Patch
Patch*
Yagi
Parabolic*
Parabolic*
Parabolic*
* Only allowed in a point-to-point network.

Approved Antennas in Europe/CE

The gain of the antenna connected to the main antenna port, minus the antenna cable
loss, must be less than 4 dB to stay below the 100-mW EIRP transmit power limit.
The AUX port is only used to receive; it never transmits.
Note: In France, the user is responsible for ensuring that the selected frequency channels comply
with French regulatory standards. At the time of this printing, only channels 10 through 13 can be
used in France.
Page 188 of 212
Pattern Gain Connector
Omni 2 dB SMA-RP
Omni 2 dB SMA-RP
Omni 3 dB SMA-RP
Omni 5 dB SMA-RP
Omni 5 dB SMA-RP
Omni 8 dB N-RP
Omni 9 dB N-RP
Omni 12 dB N-RP
Directional 8 dB SMA-RP
Directional 11 dB SMA-RP
Directional 13 dB N-RP
Directional 19 dB N-RP
Directional 14 dB N-RP
Directional 15 dB N-RP
Directional 19 dB N-RP
Directional 24 dB N-RP
Size (cm) Min. distance
from Body
7H x 1.5 20 cm
10H x 1.0 20 cm
6H x 3.0 20 cm
19H x 1.0 20 cm
19H x 1.0 20 cm
43H x 1.6 20 cm
43H x 1.6 20 cm
106H x 4.0 25 cm
15.0H x 15.0 20 cm
22 cm
22H x 12.7
28 cm
22H x 22
15.5 x 15.5 57 cm
81L x 9.0 28 cm
40H x 51W x 25D 36 cm
58H x 66W x 26D 57 cm
78H x 96W x 29D 100 cm
