ground wire
remove this connector
i210-411EX
PCIII USB EX
harness
stock connectors
8
Route the ground wire from the PCIII USB EX
under the frame and attach to the negative side
of the battery as shown in Figure D.
9
Locate the stock throttle body connector
under the fuel tank as shown in Figure E.
10 Pull straight upwards on this connector to
remove from its frame post.
11 Pull the stock connector underneath the frame.
12 Unplug the stock connector as shown in
Figure F.
2003-2006 Kawasaki Z1000 - PCIII USB EX - 3
