First you select the respective backgauge axis with help of the "Manual positioning"-key, so
that you will see the cursor bar at the required axis. Then you can move the axis with help of
the keys.
- Y-axis:
With the keys the punch can be positioned manually in the same way as for the auxiliary axes.
This operation is only possible in "Start" + " Manual Mode". Furthermore, the following
conditions must be met:
• The 'adjust' function must be active, indicated on the screen by "Adjust" in the lower
righthand corner.
• The Y-axis must be below mute-point.
• A pressing command must be given to the CNC.

5.4.2. To teach

You can teach an axis a correct position within the manual positioning mode. When you have
moved an axis to a certain position with the cursor keys, you may want to store this position.
To do so, press the ENTER key within this screen.
The actual axis value (left side) will appear in the programmed axis field (right side).
V0812, 5.6
