- Page 1 DAC-310 The compact axis control Delem E v e r y t h i n g u n d e r c o n t r o l...
- Page 2 DAC-310...
-
Page 3: Preface
Delem PREFACE This manual remains the property of Delem bv and will be placed at your disposal free of charge. It is not allowed to multiply the contents of this manual, in whole or in part, or to disclose the contents to third parties without written consent of Delem bv. - Page 4 Delem DAC-310 V0504 DAC310_gb2.doc, 2...
-
Page 5: Table Of Contents
Delem Table of contents PAGE PREFACE ................1 LIMITED WARRANTY ........... 1 INTRODUCTION............1 HARDWARE.............. 3 2.1. Front panel ...............3 2.2. Display................4 2.3. Front panel ...............4 OPERATING MODES ..........7 3.1. General................7 3.2. Manual mode..............8 3.3. Automatic mode..............9 3.4. Semi-automatic mode.............10 PARAMETER PROGRAMMING...... - Page 6 Delem DAC-310 PROGRAM CONSTANTS ........18 5.1. Selecting the program constants ........18 5.2. The parameters ..............18 V0504 DAC310_gb2.doc, 4...
-
Page 7: Limited Warranty
The DAC-310 is not confined to axis positioning but can program parameters, related to other machine functions, as well. It is possible to program several steps which can be combined to a program. - Page 8 Delem DAC-310 V0504, 2...
-
Page 9: Hardware
Delem 2. HARDWARE 2.1. Front panel The following picture shows a representation of the front panel. V0504, 3... -
Page 10: Display
Delem DAC-310 2.2. Display The DAC-310 has a monochrome LCD display, 128 x 64. The screen shows the following information: • on the left side, status information is showed, e.g. which step is active and/or which parameter • in the middle, values of parameters and position values re shown •... - Page 11 Delem • semi-automatic start key (incl. status LED) • automatic start key (incl. status LED) V0504, 5...
- Page 12 Delem DAC-310 V0504, 6...
-
Page 13: Operating Modes
Automatic mode • Semi-automatic mode. The DAC-310 can be programmed with 100 steps (0 - 99). You can browse through the steps by pressing the + and - keys. Manual mode is selected by moving to Step 0. Automatic mode is selected when a program has been entered and you move to the first step. -
Page 14: Manual Mode
4.3.8). When the stock counter reaches zero in down counting mode the DAC-310 stops. The # value is displayed at the top of the display. The back gauge can be moved manually by pressing front keys. To do so, the control must be stopped (the LED of the stop button is lit). -
Page 15: Automatic Mode
Delem Now the axis can be moved by pressing the manual movement keys on the front panel. These keys are: + = slow speed in counting up direction - = slow speed in counting down direction X = high speed, must be pressed together with the + or - key. -
Page 16: Semi-Automatic Mode
The execution cycle of a step runs similar to the one in automatic mode. There are the following differences. • The DAC-310 stops at the end of each step. • A program is started at the step that is currently selected. -
Page 17: Parameter Programming
4.1. Introduction The DAC-310 is a programmable back gauge controller. The DAC-310 can also program parameters, related to other machine functions. One such set of parameters is referred to as a "step". Several steps can be combined to build a program. During the execution of the program the steps within the program are executed one after another in an automatic cycle. -
Page 18: Programmable Parameters
Delem DAC-310 4.3. Programmable Parameters 4.3.1. General A parameter can be programmed upon selection. The selected parameter is indicated by a symbol. Selecting a parameter is done by pressing the arrow keys. The actual value of the selected parameter is displayed. -
Page 19: Cor(Rection)
Delem Everytime a step is executed, the axis moves to the programmed position Xm. The actual position is shown by Xp. When the axis has reached position, Xp has the same value as Xm. Xp is then highlighted on the display. -
Page 20: Function Outputs F
Delem DAC-310 4.3.6. Function Outputs F There are two function (on/off) outputs: F1 and F2. The value of these two outputs can be programmed as one parameter. There are four combinations: Value Default: 00 (both off) A combination can be programmed with function F. -
Page 21: Stock Counter
If in the down counting mode the value zero has been reached the DAC-310 stops and the cursor will automatically move to the #-symbol. The programmed value is reloaded if the start button is pressed. -
Page 22: Stroke S
Delem DAC-310 When programmed higher than zero, the remaining steps in the memory outside the program range are not accessible, but they remain in the memory. To access those steps, ST must be programmed back to 0. Note: the presence of this parameter depends on machine settings. - Page 23 Delem • In manual mode all parameters can always be programmed, even if the switch is in the OFF-position. • In automatic mode, the stock counter # and the correction can still be programmed. V0504, 17...
-
Page 24: Program Constants
Delem DAC-310 5. PROGRAM CONSTANTS 5.1. Selecting the program constants To enter the screen with program constants, browse to the M parameter and press ENTER. A screen with parameters appears. To return to the programming screen, press the Stop key. - Page 25 Delem Actual pos .............. 03 You can program here the position at which the axis is currently located. When you think that Xp is not showing the correct position value, program here the correct position value. Make sure this position is correct.
- Page 26 Delem DAC-310 V0504, 20...
- Page 27 Delem...
- Page 28 Delem The DAC-310 control is a compact unit for single-axis control. E v e r y t h i n g u n d e r c o n t r o l...
