Why doesn't the Nemesis respond to MIDI messages being sent to it?
By default, the Nemesis should respond to MIDI continuous controller messages on channel 1 (in
technical terms, this means that the lower 4 bits in the command byte of MIDI messages should be
0000 in binary or 0 in hexadecimal). The Nemesis's MIDI channel can be configured using the Neuro
App. Channel numbers in MIDI use zero-based counting, so MIDI channel 1 is described as 0 in
hexadecimal, MIDI channel 2 is described as 1 in hexadecimal, and so on, concluding with MIDI
channel 16, which is described as F in hexadecimal. A continuous controller message starts with a
hexadecimal B and is followed by the channel number (0 through F).
So, the command byte from your MIDI controller should be formatted as shown in the following
table:
MIDI Channel
1
(Decimal)
CC Command Byte
B0
(Hex)
Each continuous controller command byte is followed by two bytes, the CC number and the value. So,
each CC message consists of a total of three bytes. If the Nemesis is not responding to MIDI, make
sure that your MIDI controller is properly configured and sending messages in the format described
above.

MIDI Implementation

Program Change Messages
By default, the Nemesis responds to Program Change messages as shown in this table:
Parameter
Enable Preset 1
Enable Preset 2
Enable Preset 3
Enable Preset 4
Enable Preset 5
Enable Preset 6
Enable Preset 7
Enable Preset 8
Enable Preset 9 to 128
To bypass the Nemesis using Program Change messages, just set up one of the 128 presets with the
effect bypassed, and recall that preset when you need to bypass the Nemesis.
Clock Messages
The Nemesis responds to MIDI beat clock (decimal 248, hex 0xF8), which should be sent at a rate of
24 ppqn (pulses per quarter note). The Nemesis does not respond to clock start (0xFA), clock
continue (0xFB), or clock stop (0xFC) messages. The Nemesis does not respond to MIDI timecode.
SA260
2 3 4 5 6 7
B1 B2 B3 B4 B5 B6
Message Type Data Value
Program Change 000
Program Change 001
Program Change 002
Program Change 003
Program Change 004
Program Change 005
Program Change 006
Program Change 007
Program Change 008 to 127
Nemesis Delay User's Guide
8 9 10 11 12 13
B7 B8 B9 BA BB BC
14 15 16
BD BE BF
