5.2

Check the Ethernet cable

If the radio's Ethernet port is connected and the Ethernet LED does not light on
the radio, there may be a problem with the Ethernet cable. Verify the cable is
plugged into the radio at one end, and to an Ethernet hub or a 10/100/1000
Base-T Ethernet switch at the other end.
If using the PoE injector, verify that the M12 to RJ45 cable is connected between
the radio and the injector and also that the Ethernet patch cable is connected
between the injector and switch.
Note: The RLX2 radio auto-detects the Ethernet connection type, and does not require a crossover
cable for direct connection to a PC.
