RLX2 Quick Setup
User Manual
2.3

Setup Client Radio

RLX2 radios can be configured in Client mode. Client mode radios only support
one wired network device, but can connect to third-party 802.11 Access Points.
The following table highlights the most significant differences between Repeater
and Client modes on RLX2 radios:
Number of attached
Ethernet devices
supported
Can connect to other
RLX2 Repeaters?
Can connect to non-
ProSoft Access Points
(Masters)?
MAC address seen on
network
Client mode radios are not often necessary in Industrial network applications. If
the need for a Client RLX2 radio in the system is not needed, this example
configuration can be skipped.
The most straightforward way to test a Client mode radio configuration is with a
second PC connected as the downstream network device from a Client radio. We
will assume such a setup in the following example, and will connect to the Master
radio we configured previously.
Page 30 of 161
Repeater
Many (up to limits of
network)
Yes
No
Repeater radio's MAC
address
RLX2 Series ♦ 802.11a, b, g, n
Industrial Hotspot
Client
One
No
Yes
MAC address of
connected device, or
user-specified MAC
address.
ProSoft Technology, Inc.
May 8, 2013
