Default Gateway
The IP address of a network router where data is sent if the destination IP
address is outside the local subnet. The gateway is the device that routes the
traffic from the local area network to other networks such as the Internet.
Device-to-Device Network (Peer-to-Peer Network)
Two or more devices that connect using wireless network devices without the
use of a centralized wireless access point. Also known as a peer-to-peer
network.
DFS
DFS stands for Dynamic Frequency Selection, a requirement for operation on
certain frequencies in the 5 GHz band in many countries. When a radio operates
on a DFS frequency, it must sense the presence of radar and automatically
change to another channel if radar is detected.
DHCP
The dynamic host configuration protocol is an Internet protocol, similar to BootP,
for automating the configuration of computers that use TCP/IP. DHCP can be
used to automatically assign IP addresses, to deliver IP stack configuration
parameters, such as the subnet mask and default router, and to provide other
configuration information, such as the addresses for printer, time, and news
servers.
Direct Sequence Spread Spectrum
One of two approaches (with frequency hopping spread spectrum) for sorting out
overlapping data signals transmitted via radio waves. 802.11b uses DSSS
Directional Antenna
Transmits and receives radio waves off the front of the antenna.
Diversity Antenna
An antenna system that uses multiple antennas to reduce interference and
maximize reception and transmission quality.
DTE
Data Terminal Equipment, for example, a computer or terminal.
Dual Band
A device that is capable of operating in two frequencies. On a wireless network,
dual-band devices are capable of operating in both the 2.4 GHz (802.11b/g) and
5 GHz (802.11a) bands.
EAP
Extensible Authentication Protocol. A protocol that provides an authentication
framework for both wireless and wired Ethernet enterprise networks.
