To use the installation tool, insert it into the connector as shown:
Press down on the installation tool to use it as a level which will open the
connector's contacts to insert a wire. A properly-wired power connector is shown:
The RLX2 radios accept power from 802.3af Mode B or passive Power over
Ethernet sources supplying 48VDC, with an average power draw of less than 8
watts. ProSoft offers the following passive PoE injectors for use with the RLX2
radios:
POE-48I-AC
POE-48I-DC-DC
The radio shall be installed by trained personnel only, as outlined in the
installation instructions provided with each radio.
Page 124 of 161
Power over Ethernet Injector, AC input
Power over Ethernet Injector, 9 to 36 VDC input voltage
