ProSoft Technology RLX2-IHA User Manual page 79

RLX2 Series ♦ 802.11a, b, g, n
Industrial Hotspots
Field
Delineation Method
EOL Delineator
EOL Time Gap
Packet Rate
(milliseconds)
Baud Rate
Data Bits
Parity
Flow Control
Stop Bits
Save
Cancel
ProSoft Technology, Inc.
May 8, 2013
Description
None: All data received between packet delineation events is sent to
the remote node in a single network frame.
Time Gap: The minimum time gap between characters that is to be
interpreted as a delineator for a packet. Configure this value in the
EOL Time Gap field.
Character: The particular character sequence in the stream of
characters that indicates the delineator for the packet. Configure this
value in the EOL Delineator field.
Available when the selected Delineation Method is Character. Choose
the type of delineator to use from the dropdown list:
Available delineation types are:
Decimal Hex
Type
Use Text
13 0D
CR
27 1B
ESC
10 0A
LF
00 00
Null
32 20
Spacebar
09 09
Tab
Available when the selected Delineation Method is Time Gap; This
value configures the length of time in milliseconds that must elapse
after a character is received (from the local attached device) before
that character marks the end of a packet.
NOTE: the smallest value this field can be set to will be limited by the
device and is platform dependent.
Sets the minimum time gap that will be interpreted as an inter-packet
space. When detected the characters received up to that point will
constitute a single packet and will be sent to the remote node. Units:
microseconds. Values: 1,000 to 500,000.
Baud rate on the radio must match the baud rate on the connected
serial device.
Number of data bits (5, 6, 7 or 8). The data bits on the radio must
match the data bits on the connected serial device.
Parity (None, Even, Odd, 1 or 0). The parity on the radio must match
the parity on the connected serial device.
Flow control (handshaking) mode (None or Hardware). The
handshaking mode on the radio must match the handshaking mode on
the connected serial device.
Stop bits (1 or 2). The stop bits on the radio must match the stop bits
on the connected serial device.
Saves the changes and updates the radio configuration.
Discards the changes without updating the radio configuration.
Detailed Radio Configuration / Diagnostics
Description
Any string of characters
Carriage Return
Escape
Line Feed (New Line / nl)
Null
Space
Horizontal Tab
