1.1

About this manual

This manual covers the entire RadioLinx® RLX2 Industrial Hotspot™ series of
radio products. There are four products available in this product line:
Model
Except for different operating frequencies and output power levels, these radios
all operate in a similar fashion. Different models operating on common
frequencies can communicate with each other. Furthermore, most RLX2 series
radios (except RLX2-IHNF) can communicate with ProSoft Technology's legacy
RLXIB series of radios. Details on the specific differences between the RLX2 and
RLXIB series products can be found in the Compatibility with ProSoft RLXIB
Series Radios section on page 117.
When a feature is described in this manual that is unique to a specific RLX2
model, it will be highlighted like this:
1.2 About the RadioLinx

1.2.1 General Features

The RadioLinx
radios, with Power Over Ethernet (PoE) and Serial Encapsulation. All radios
operate at speeds up to 54 Mbps, and the RLX2-IHNF operates at speeds up to
300 Mbps. Designed for industrial installations, the RLX2 series offer many
features including hazardous location certifications, IGMP Snooping, OFDM for
noise immunity, repeater mode to extend range, automatic parent selection for
self-healing, OPC server diagnostics, extended temperature, high vibration/shock
and DIN-rail mounting.
Page 12 of 161
Standards
IEEE 802.11a
IEEE 802.11b/g
IEEE 802.11a/b/g/n
IEEE 802.11a/b/g
This features applies to the RLX2-IHNF only
®
RLX2 Industrial Hotspot™ products
®
802.11 Industrial Hotspots™ are high-speed wireless Ethernet
RLX2 Series ♦ 802.11a, b, g, n
Maximum Output Power
24 dBm (250 mW)
24 dBm (250 mW)
17 dBm (50 mW)
20 dBm (200 mW)
