RLX2 Series ♦ 802.11a, b, g, n
Industrial Hotspots
6

Detailed Radio Configuration / Diagnostics

In This Chapter
 Radio Status .......................................................................................... 54
 Radio Network Settings ......................................................................... 60
 Security settings .................................................................................... 80
 Radio access settings ........................................................................... 84
 Apply Changes ...................................................................................... 86
 Cancel Changes .................................................................................... 87
 Factory Defaults .................................................................................... 87
 DFS Support .......................................................................................... 87
The RadioLinx Industrial Hotspot radio has a built-in Radio Configuration /
Diagnostic Utility (radio web configuration form) that allows the configuration of
the radio from any computer that can connect to the radio, through a wired
Ethernet connection, or through a Wireless connection.
A web browser such as Microsoft Internet Explorer or Firefox on a network-
enabled desktop computer, laptop or Personal Data Assistant (PDA) can be used
to monitor and change the settings within the RadioLinx Industrial Hotspot radio.
To open the Radio Configuration / Diagnostic Utility
In the RadioLinx Industrial Hotspot Browser, select the radio to configure from
1
the list view or topography view, and then click the right mouse button to
open a shortcut menu.
On the shortcut menu, choose Connect. The Radio Configuration / Diagnostic
2
Utility will open in the web browser.
Or,
Double-click the selected radio to launch the Radio Configuration / Diagnostic
Utility.
Also, the Radio Configuration / Diagnostic Utility can be opened directly from the
web browser.
Important: The desktop computer, laptop, or PDA must be connected to the same network as the
RadioLinx Industrial Hotspot radio.
Open a web browser.
1
In the address bar, type "
2
and then click the "Go" button. For example,
http://192.168.6.10
ProSoft Technology, Inc.
May 8, 2013
", followed by the IP address for the radio,
http://
Detailed Radio Configuration / Diagnostics
Page 51 of 161
User Manual
