Contents
Introduction .......................................1
About this Guide . ...............................1
About the DMS 1600 and DMS 3600 2
Configurability ...................................3
Installation .........................................5
Rear Panel . ..........................................5
A Note on I/O Boards . ....................5
Making Connections . .....................7
Front Panel .........................................8
Front Panel Operations . ...................9
Creating a Tie .....................................9
Viewing Ties
(and Muting Outputs) . .......................9
Saving or Recalling a Preset ............10
Locking Out the Front Panel
(Executive Mode) .............................10
Remote Control ...............................11
Selected SIS Commands ...................11
Establishing a Network
(Ethernet) Connection . ................11
Establishing a USB Port
Connection . ..................................12
Host-to-Switcher instructions . .....13
Command/Response Table
for SIS Commands . .......................14
Installing and Starting the
Control Program ..............................18
Installing the Program . ................18
First-time Connection
Considerations .............................19
Starting the Program . ..................20
Accessing the HTML Pages ..............22
Configuring for Network
Communication ...........................22
Loading the Start-up Page ..........23
Maintenance and Modifications .25
Removing and Installing
an I/O Board or Blank Panel ............25
Removing and Installing
a Power Supply Module . ..................27
Removing and Installing
a Fan .................................................29
DMS 1600 and DMS 3600 • Contents i
