External Antenna Rf Connector - Javad HPT404BT Operator's Manual

Specifications
Connector Specifications
Receiver Specifications
This connector provides DB15 connectivity for the HPT404BT with DTE. About using and configuration
RS-485 please contact JAVAD GNSS support.

External Antenna RF Connector

The external antenna connector type is a BNC RF connector AEP Connectors p/n 6501-7051-003.
38
Table A-5. DB15 Connector Specifications
Number Signal Name
1 DCD_OUT
2 DTR_OUT
3 RX+/CTS_IN
4 RX-/RX_IN
5 PWR_IN
6 USB_PWR
7 Ground
8 PWR_IN
9 DSR_IN
10 TX+/RTS_OUT O
11 TX-/TX_OUT
12 Ground
13 USB_D+
14 USB_D-
15 Ground
Dir Details
O Data Carrier Detect (RS-232)
O Data Terminal Ready (RS-232)
I Receive Data positive line (RS-422)/
Clear to Send (RS-232)
I Receive Data negative line (RS-422)/
Receive Data (RS-232)
I +9 to +36 VDC Power Input
I Power Input line (USB)
- Power Ground
I +9 to +36 VDC Power Input
I Data Set Ready (RS-232)
Transmit Data positive line (RS-422) /
Request to Send (RS-232)
O Transmit Data negative line (RS-422) /
Transmit Data (RS-232)
- Power Ground
I/O Positive line (USB)
I/O Negative line (USB)
- Power Ground
