3.4.3. SAVE
The SAVE command is intended to store the unit's currently used configuration into the User
Configuration file. The configuration stored in the User Configuration file is activated by automatically
after unit's reboot.

3.4.4. SLEEP

The SLEEP command determines the sleep mode parameters. The sleeping AW435BT can be activated
by real-time CLK, DTR/RTS lines, and command received through TTL inputs. The user can select one,
two, or all three conditions.
SLEEP [Parameter Name] [Parameters List] [/?]
Parameter Name
CLK
HW
TTL
GTS
32
0 – Do not activate by internal real-time clock
(1 – 255) – Activate by internal real-time clock after 100 to 25500 msec of sleeping
0 – Do not activate through DTR/RTS lines
1 – Activate through DTR/RTS lines
0 – Do not activate by external sense lines
1 – Activate by external sense lines
0 – Disable Sleep mode (default)
(1 – 255) – Go to sleep mode if there is no activity in 10 to 2550 msec
Parameter List
