HPT435BT JL
UHF Modem
User manual
Version 1.1
Last Revised June 3, 2020
All contents in this manual are copyrighted by JAVAD GNSS.
All rights reserved. The information contained herein may not be used, accessed, copied,
stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express
written consent from JAVAD GNSS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HPT435BT JL and is the answer not in the manual?

Questions and answers

Related Manuals for Javad HPT435BT JL

Summary of Contents for Javad HPT435BT JL

  • Page 1 Version 1.1 Last Revised June 3, 2020 All contents in this manual are copyrighted by JAVAD GNSS. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, or distributed, or otherwise reproduced without express...

  • Page 3: Terms And Conditions

    GNSS”) for owners of JAVAD GNSS products. It is designed to assist own- BE LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS ers with the use of HPT435BT JL and its use is subject to these terms and CONTAINED HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL conditions (the “Terms and Conditions”).

  • Page 4: Regulatory Information

    Software license, warranty and limitation of liability). Réglement sur le matériel brouilleur du Canada. SAFETY – Improper use of HPT435BT JL can lead to injury to persons or Industry Canada property and/or malfunction of the product. The HPT435BT JL modem should only be repaired by authorized JAVAD GNSS warranty service The term “IC:”...

  • Page 5: Manual Conventions

    This is normal and not a cause for concern. TECHNICAL ASSISTANCE If you have a problem and cannot find the information you need in the product documentation, contact your local dealer. Alternatively, re- quest technical support using the JAVAD GNSS World Wide Web site at: www.javad.com. www.javad.com...

  • Page 6: Getting Acquainted

    INTRODUCTION The HPT435BT JL devices contains a 35 W UHF (406 to 470 MHz) radio GETTING ACQUAINTED transceiver. HPT435BT JL can be configured and supported using web-interface HPT435BT JL is a device designed for organizing a local network be- through Internet, and this makes the setup mechanism simple and ac- tween different devices via Wi-Fi, Ethernet, and Bluetooth, connecting cessible from anywhere in the world.

  • Page 7: Installation

    Warning: To avoid serious damage of the equipment, do not use the radio without the antenna. 2. Connect HPT435BT JL to external power supply (9…16 V). 3. Insert optional SIM card and SD card to the appropriate card slot if you would like to use GSM connection to connect to the Internet.

  • Page 8: Antenna Installation

    Outdoor Use and have an output rated for +9 ... +16V, 10A. This may not • UHF NGP Antenna 450-470 MHz, 1/2, 2.4 dBd gain, NMO be the same range as other JAVAD GNSS products with which you are familiar.
  • Page 9 • Attach cable with ground plane to the UHF antenna; move the signal between the radio and the antenna: • UHF Ant Cable TNC/Pole Mount, 12ft • UHF Ant Cable TNC/Magn Mount, 12f • UHF Ant Cable TNC/Mini-Magn Mount, 12ft • Place the antenna on the pole. www.javad.com...

  • Page 10: Setup And Configuration

    SETUP AND CONFIGURATION 1. Turn on power of HPT435BT JL. The most efficient way to increase duty cycle of the HPT435BT JL trans- ceiver is using the Fan kit (p/n 02-587101-31) shown on the picture be- 2. Wait for complete loading. When it is complete, Power LED will blink.
  • Page 11 Wi-Fi interface on. Select the network you would like to con- nect in the Communication/Wi-Fi tab, enter password to get access and wait for the connection see below. More detailed connection status you can check in Status/Wi-Fi tab. www.javad.com...
  • Page 12 NTRIP Client to Serial Port The following are the steps of configuration of HPT435BT JL: 1. Connect to HPT435BT JL via web interface as described above. 2. Configure the Cellular (GSM ): In the Communication/GSM tab set the PIN code and APN parameters (if necessary);...
  • Page 13 Setting” button and wait until finish. Figure 14. HPT435BT JL GSM Status tab It is possible also to connect HPT435BT JL to Internet via LAN or Wi-Fi using any Wi-Fi router, MiFi device or even smart-phone configured in hot spot mode.
  • Page 14 Figure 17. HPT435BT JL NTRIP Data Router tab 6. Setup NTRIP Client. In the Services/NTRIP tab set following parame- Figure 18. HPT435BT JL NTRIP configuration tab ters: “Server name/address”, “Port”, “User” , “Password” . Click “Save Setting” button and wait until finish.
  • Page 15 UHF channel (in Satel mode) to Serial Port The following are the steps of configuration of HPT435BT JL: 1. Connect to HPT435BT JL via web interface as described above. Figure 21. HPT435BT JL Power Management tab 2. UHF configuration in Satel mode: Detailed connection status you can check in Status/UHF int.
  • Page 16 Figure 23. HPT435BT JL Advanced tab Figure 25. HPT435BT JL UHF Modem Router tab 4. Reboot device 6. Connect Serial Port In the Administration/Management tab click “Reboot” button and wait Use any application to connect serial port of HPT435BT JL with follow- www.javad.com...
  • Page 17 TRIUMPH-2 services through Internet JL receives data from internet and redirects it to its Wi-Fi clients. Data In this configuration HPT435BT JL will share its internet connection (es- packets received by 1110-1119 ports will be redirected to Wi-Fi. tablished by GSM interface) with TRIUMPH-2 connected to HPT435BT JL Wi-Fi client which IP address is 10.1.10.110.
  • Page 18 After restarting the device you can check the Wi-Fi connection in the Parameters/Networking/Server , to setup Service port. web interface Status/Wi-Fi tab of HPT435BT JL. • Set the TCP/FTP parameter: TCP Port (1125). • Set the TCP/FTP parameter: TCP Output Base Port (1120).
  • Page 19 900 Rock Avenue, San Jose, CA 95131, USA Phone: +1(408)770-1770  Fax : +1(408)770-1799 www.javad.com All rights reserved © JAVAD GNSS, Inc., 2020...
