External Antenna RF Connector

The external antenna connector type is a BNC RF connector AEP Connectors p/n 6501-7051-003.
www.javad.com
Table A-6. DB15 Connector Specifications
Signal Name Dir
DCD_OUT O Data Carrier Detect (RS-232)
DTR_OUT O Data Terminal Ready (RS-232)
RX+/CTS_IN I Receive Data positive line (RS-422)/
Clear to Send (RS-232)
RX-/RX_IN I Receive Data negative line (RS-422)/
Receive Data (RS-232)
Not used - Do not use
USB_PWR I Power Input line (USB)
Ground - Power Ground
Not used - Do not use
DSR_IN I Data Set Ready (RS-232)
TX+/RTS_OUT O Transmit Data positive line (RS-422) /
Request to Send (RS-232)
TX-/TX_OUT O Transmit Data negative line (RS-422) /
Transmit Data (RS-232)
Ground - Power Ground
USB_D+ I/O Positive line (USB)
USB_D- I/O Negative line (USB)
Ground - Power Ground
