depending on the charts you use. This section shows menus from
an Insight chart.
Ú Note:
A menu option is greyed out if it is not available on the
chart displayed. For example, raster charts are not available with
Insight, so the Raster charts menu option is greyed out when
Insight charts are displayed.
Insight and C-MAP tides and currents
The system can display Insight and C-MAP tides and currents. With
this information it is possible to predict the time, level, direction and
strength of currents and tides. This is an important tool when
considering planning and navigation of a trip.
In large zoom ranges the tides and currents are displayed as a
square icon including the letter T (Tides) or C (Current). When you
select one of the icons, tidal or current information for that location
are displayed.
Dynamic current data can be viewed by zooming inside a 1-nautical
mile zoom range. At that range, the Current icon changes to an
animated dynamic icon that shows the speed and direction of the
current. Dynamic icons are colored in black (greater than 6 knots),
red (greater than 2 knots and less than or equal to 6 knots), yellow
(greater than 1 knot and less than or equal to 2 knots) or green
(equal to or less than 1 knot), depending on the current in that
location.
If there is no current (0 knots) this will be shown as a white, square
icon.
Static Current and Tide icons
Charts | GO XSE Operator Manual
Dynamic Current icons
