Summary of Contents for Simrad E5024 ECDIS
- Page 1 E5024 ECDIS System Installation Manual ENGLISH...
- Page 3 The Wheelmark The Simrad E5024 ECDIS system is produced and tested in accordance with the European Council Directive 96/98/EC of December 1996 on marine equipment, as last amended by directive 2013/52/EU. This means that the system complies with the highest level of tests for nonmilitary marine electronic navigation equipment existing today.
-
Page 4: About This Manual
• Navionics is a registered trademark of Navionics SpA • Simrad is a trademark of Kongsberg Maritime AS Company registered in the US and other countries and is being used under license • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo... -
Page 5: Table Of Contents
Spare parts and accessories E5024 ECDIS system NSO evo2 accessories Ethernet cables Supported data ECDIS NMEA 0183 & NMEA 2000 supported sentences E5000 Processor specifications Dimensional drawings E5000 Dimensional drawings LTSX50N8 trackball dimensional drawings Contents | E5024 ECDIS Installation Manual... -
Page 6: E5024 System Overview
Synchronizing the ECDIS CPU with a backup ECDIS device constitutes a PLECDIS system (PaperLess ECDIS). Integration is possible with Navico ARGUS radar. The Simrad M5024 monitor offers a low profile, high brightness solution for displaying video from a variety of sources. M5024 monitors are color calibrated according to ECDIS requirements. - Page 7 Installation kit: Cable retainer Cable ties, 102 mm x 2.5 mm, black Pan head screws, 19 mm x 3.5 mm, phillips #2 Pan head screws, 25 mm x 4 mm, phillips #2 E5024 System overview | E5024 ECDIS Installation Manual...
-
Page 8: E5000 Cpu
The alarm output pin is dedicated to the ECDIS software, and will not be triggered by NSO software • There will only be one free serial input to the NSO software. This can be used for Touch screen OR NMEA 0183 input E5024 System overview | E5024 ECDIS Installation Manual... -
Page 9: Hardware Installation
When drilling into fibreglass covered in gelcoat, it is recommended to carefully remove the gelcoat layer with a small countersink bit after the hole has been drilled. This will prevent the gelcoat from cracking as the fastener is tightened. = PHILLIPS #2 (PH2) Hardware installation | E5024 ECDIS Installation Manual... -
Page 10: M570 Trackball
The optional LTSX50 is a panel mounted, waterproof (IP 68) trackball with scroll wheel. The LTSX50 must be plugged into one of the two USB ports on the E5000 processor. For dimensions see “LTSX50N8 trackball dimensional drawings” on page 39. Hardware installation | E5024 ECDIS Installation Manual... -
Page 11: Wiring
ECDIS requirements demand the system to automatically restart after a power-loss. For ECDIS compliance, yellow wire must be connected to a switch / circuit breaker in such a way that it is running at 12/24V during normal operation. Wiring | E5024 ECDIS Installation Manual... -
Page 12: External Alarm
Blue alarm pin E5000 E0102 separate power For wiring details for the E0102, refer to the included manual. ¼ Note: The E5000 processor and E0102 alarm panel must have separate power supplies to be compliant. 10 | Wiring | E5024 ECDIS Installation Manual... - Page 13 Connecting monitors Two displays may be connected to the E5000 via the HDMI ports. The ECDIS CPU (HDMI 1 OUT) must be connected to a Simrad M5024 to conform to IMO requirements. The NSO evo2 CPU (HDMI 2 OUT) can connect to a wide range of supported monitors; the Simrad DI-15, MO-L 15/17/19, MO16/19/24 (T&P), legacy MO-19, B&G ZM series, and KEPMGB-...
-
Page 14: Connecting Control Devices
Micro-C power cable. Connected to backbone via a T-connector ¼ Note: Most NMEA 2000 devices can be connected directly to a Simrad SimNet backbone and SimNet devices can be connected to a NMEA 2000 network by using adapter cables. 12 |... - Page 15 ¼ Note: Simrad devices with Micro-C NMEA 2000 connectors are fully compatible with a SimNet network by using a Micro-C to SimNet adapter cable. Power the CAN bus The network requires its own 12 V DC power supply protected by a 5 amp fuse or breaker. For vessels fitted with 24 V systems, use a DC-DC converter to supply 12 V.
-
Page 16: Nmea 0183 Device Connection
38,400 baud. Set the serial port baud rate to the same rate as used by the con- nected equipment. ¼ Note: AIS is not internally bridged, so it must be connected to one NMEA 0183 port on each CPU if required on both screens. 14 | Wiring | E5024 ECDIS Installation Manual... -
Page 17: Ethernet Device Connection
To achieve a PLECDIS system (PaperLess ECDIS), two E5000 processors must be connected together via ethernet to allow synchronization. The connection can be made using a standard ethernet patch cable with RJ45 plugs at each end. | 15 Wiring | E5024 ECDIS Installation Manual... -
Page 18: Getting Ready To Use The System
User permit code from the System Settings dialog. This code is sent to Navico by email at chartservice@navico.com. ¼ Note: You can NOT save the User permit code to the NavStick. 16 | Getting ready to use the system | E5024 ECDIS Installation Manual... - Page 19 Select the charts you want to install Enter a new name or select an existing name for the SENC geodatabase destination Selected charts and license codes are now copied to the E5024 system. | 17 Getting ready to use the system | E5024 ECDIS Installation Manual...
-
Page 20: Installing Charts From Other Suppliers
If you have more than one database available, you can select to show multiple charts. The system will however only display one chart at the time, and it will automatically select the best chart available based on your vessel’s position. 18 | Getting ready to use the system | E5024 ECDIS Installation Manual... -
Page 21: Ecdis Software Setup
¼ Note: Most screenshots shown have been cropped to optimize display of relevant content. Chart settings Refer to the E5024 ECDIS Operator Manual. Vessel settings Display settings Refer to the E5024 ECDIS Operator Manual. | 19... - Page 22 Select Parameters from the Vessel settings to enter vessel’s unique identification details. ¼ Note: The MMSI number is required to prevent own vessel’s AIS target appearing overlaid on the vessel icon, and causing false alarms as a dangerous target. 20 | ECDIS Software setup | E5024 ECDIS Installation Manual...
- Page 23 NMEA sentences. This allows the system to listen only to a specific talker. A wildcard (*) can be used to listen to messages from all sources of the type selected. | 21 ECDIS Software setup | E5024 ECDIS Installation Manual...
- Page 24 2000 Deleting a sensor To remove a sensor that is no longer required, open the sensor settings by choosing the sensor icon. Select Delete at the bottom of the page. 22 | ECDIS Software setup | E5024 ECDIS Installation Manual...
-
Page 25: Websocket Interface Connection
Websocket interface connection The Simrad web interface is an easy to use web-style portal that lets you configure NMEA 2000 sensors. You can access the Sources, the Device list, and configure most of the hardware available in the system. - Page 26 ¼ Note: Ensure that your computer’s network settings are set so you can access this IP address Once connected correctly the Simrad web interface home screen will appear ¼ Note: It will say Connected in the top right-hand corner of the screen next to the help tab. If it says Not Connected then check the E5000 power and connections, and network activity light on both devices.
-
Page 27: Ais Settings
Selecting the help tab located in the top righthand corner of the screen will show the help files related to the current page or feature. AIS settings Refer to the E5024 ECDIS Operator Manual. Radar targets settings Refer to the E5024 ECDIS Operator Manual. -
Page 28: Radar Settings
• Check Enabled to turn on overlay • The Data port setting should not need adjustment as is set by default for Simrad IMO radar • Set the Data received timeout, to stop overlay if no fresh data is provided •... -
Page 29: System Settings
Used to change the color palette. For more information refer to the E5024 Operator Manual. Sound Used to turn the alarm sound On or Off. On-screen keyboard Used to turn On / Off the virtual keyboard. | 27 ECDIS Software setup | E5024 ECDIS Installation Manual... - Page 30 To install an SA certificate: Go to Settings, System, and then select SA certificates. A list of the currently installed SA certificates found in the E5024 ECDIS system will open ¼ Note: When you open the SA certificates panel for the first time after the E5000 ECDIS system launch, the SA certificates launch will start automatically.
-
Page 31: System Information
If you check the Automatic backup the SENC geodatabases, Mariner objects, Routes, Permits, and Configuration files are synchronized automatically. ¼ Note: Manual synchronization can be done by accessing the Menu, Tools, and Backup ar- rangement settings. | 29 ECDIS Software setup | E5024 ECDIS Installation Manual... -
Page 32: Alarms Settings
¼ Note: All depth and height values are related to the sounding and vertical datums of the chart under the own vessel. Tides ARE NOT taken in consideration. 30 | ECDIS Software setup | E5024 ECDIS Installation Manual... - Page 33 • To turn the alarm on, tick on the Lost AIS target alarm check box. The indication is removed from the chart view | 31 ECDIS Software setup | E5024 ECDIS Installation Manual...
- Page 34 • To turn the alarm on, tick on the Lost radar target alarm check box. The indication is removed from the chart view 32 | ECDIS Software setup | E5024 ECDIS Installation Manual...
-
Page 35: Installation Approval
Output SI80 CH1 input Output SI80 CH2 input Output SI80 CH3 input Output SI80 CH4 input Output External Ethernet connections Refer Yes/No Type of equipment Ethernet 1 Ethernet 2 Ethernet 3 | 33 Installation approval | E5024 ECDIS Installation Manual... -
Page 36: Spare Parts And Accessories
SimNet to Micro-C female plug, 1m (cable for connection of a NMEA 2000 data device to SimNet backbone) 24006413 SimNet to Micro-C female, 4m (13 ft) (cable for connection of a NMEA 2000 data device to SimNet backbone) 34 | Spare parts and accessories | E5024 ECDIS Installation Manual... -
Page 37: Ethernet Cables
000-0127-30 Ethernet cable yellow 5 Pin 7.7 m (25 ft) 000-0127-37 Ethernet cable yellow 5 Pin 15.2 m (50 ft) 000-11246-001 Ethernet adaptor cable, yellow 5 Pin - RJ45 | 35 Spare parts and accessories | E5024 ECDIS Installation Manual... -
Page 38: Supported Data
127258, 129025, Recommended 129026, 129033 Minimum Specific GNSS Data ROT – Rate Of 127251 Turn THS – True 127250 Heading and Status TLB – Target Label TLL – Target Latitude and Longitude 36 | Supported data | E5024 ECDIS Installation Manual... - Page 39 Message VDO – AIS VHF Data-Link Own- Vessel Report VHW – Water 127250,128259 Speed and Heading VTG – Course 129026 Over Ground & Ground Speed ZDA – Time & 129033 Date | 37 Supported data | E5024 ECDIS Installation Manual...
-
Page 40: E5000 Processor Specifications
4800, 9600, 19200, & 38400 (via proprietary cable) RS422 port baud rate 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 Charting support E5024 ECDIS system: S57 or S63 approved ENC charts NSO evo2: Refer to NSO evo2 Operator Manual 38 | E5000 Processor specifications |... -
Page 41: Dimensional Drawings
The dimensional drawings for the monitor and alarm panel are found in a separate document. LTSX50N8 trackball dimensional drawings 59,70 mm 116,00 mm 16,70 mm 104,00 mm 41,00 mm 2,00 mm | 39 Dimensional drawings | E5024 ECDIS Installation Manual...
