Setting up the audio system

Audio mixer
Use the Mixer to:
• Adjust the balance, volume, and volume limits individually for
each zone.
• Adjust the bass and treble, and the balance between zones.
Turn on or off individual speaker zones in the Master control.
•
The Mixer options vary depending on the activated audio device.
The following is an example of the USB source mixer option for the
All Zones:
• Bass
• Middle
• Treble
The speakers
Speaker zones
The GO XSE can be set up to control different audio zones. The
number of zones depends on the audio server connected to your
system.
Audio | GO XSE Operator Manual
Tuner VHF
Select to
display the
favorite
stations for the
tuner
Select to display optional settings for active
source
Playback
Select to
display the
Device
Select to explorer. Use
display the the explorer to
favorite access the
channels for source's native
the VHF controller or
file structure
and to select
tracks.
163
