Precipitation
Shades of color are used to show precipitation type and intensity.
The darkest color indicates the highest intensity.
Rain
Snow
Mixed
Sea Surface Temperature (SST)
You can show the sea surface temperature as color shading or as
text.
When color coding is selected, the SST color bar is shown on the left
side of the display.
You define how the color codes are used to identify sea surface
temperature. See "Adjusting color codes" on page 178.
Wave indication
Colors are used to indicate forecasted wave height. The highest
waves are dark red, while the lowest are blue.
You can define how the color codes are used to identify the wave
height. Refer to "Adjusting color codes" on page 178.
Surface features
Turns surface features on/off. Surface features include fronts, isobars,
and pressure points. Surface features cannot be shown at the same
time as Wind.
Cloud tops
Turn Cloud tops on/off. Cloud tops indicate the height of the top of
the clouds. The color palette used is grey with darker greys
indicating lower clouds. Cloud tops cannot be shown at the same
time as Precipitation or Echo Tops.
Ú Note:
This feature is only available for certain SiriusXM
subscriptions.
Weather | GO XSE Operator Manual
From light green (light rain) - yellow - orange - to
dark red (heavy rain)
Blue
Pink
