Chapter 1- Hardware Description

RMX 2000 LEDs

RMX 2000 Front Panel LEDs

1-22
The RMX includes LEDs located on the front panel and rear panel. In the
front panel, the LEDs reflect the state of the components. The LEDs on the
rear panel indicate the state of the external connections and the status of
the RTM IP card.
The following items appear on the RMX 2000 front panel:
Table 1-1 RMX 2000 Front Panel LED's
Component LED ID
Fan Status
Power Status
LED Color Description
Green OK.
Red Warning - Fan or power failure.
Green OK.
Red Error - Problem with power supply.
When the power cable is
unplugged, the FAIL LED is lit 2-3
seconds before turning OFF.
